10
Application Information
Unit Installation
F series
Ceiling Opening Size = 890mm
Hanging rod size = 780mm
Ceiling Opening Size = 890mm
Hanging rod size = 710mm
WA
TER DRAINAGE
PIPING DIRECTION
LED
REFRIGERANT
PIPING DIRECTION
W
A
TER DRAINAGE
PIPING DIRECTION
REFRIGERANT
PIPING DIRECTION
LED
WA
TER DRAINAGE
PIPING DIRECTION
LED
REFRIGERANT
PIPING DIRECTION
W
ATER DRAINAGE
PIPING DIRECTION
LED
REFRIGERANT
PIPING DIRECTION
11
13
Table of Contents
Technical Manual
2
Default Chapter
2
