ESIE15-13B Field Setting from Outdoor Unit PCB
Field Setting 85
 Setting of Demand 2 operation
With this setting, compressor operation can be controlled to reduce power consumption.
(60% - 80% demand is available when a demand adapter (optional accessory) is used.)
[Work procedure]
Setting item Setting condition Description
Demand 2 operation
30% demand
Operates with 30% of rated
power consumption.
40% demand (factory setting)
Operates with 40% of rated
power consumption.
50% demand
Operates with 50% of rated
power consumption.
h: OFF l: BLINK k: ON
Operating procedure
H1P H2P H3P H4P H5P H6P H7P
Push and hold the MODE (BS1) button of "Setting mode 1" for 5 seconds
or more and set to "Setting mode 2."
khhhhhh
Push the SET (BS2) button three times to set the LED display as shown
in the table on the right.
khhhhkk
Push the RETURN (BS3) button once. (Present settings are displayed.) khhhhlh
Push the SET (BS2) button to set the LED
display as shown in the table on the right.
30% of rated power consumption
khhhlhh
40% of rated power consumption
khhhhlh
50% of rated power consumption
khhhhhl
Push the RETURN (BS3) button once to make a
decision.
30% of rated power consumption
khhhkhh
40% of rated power consumption
khhhhkh
50% of rated power consumption
khhhhhk
Push the RETURN (BS3) button once again for execution. (The LED
display is in the initial status of "Setting mode 2".)
khhhhhh
Push the MODE (BS1) button once to return to Setting mode 1 (normal
operation).
hhhhhhh
