Daikin FAQ71BVV1B Techical Data

• Indoor Units • R-410A • FAQ-BVV1B
6
• Split Sky Air • Indoor Units
8
6 Dimensional drawing & centre of gravity
6 - 1 Dimensional drawing
3D038540 C
unit (mm)
50 or more
30 or more
(Required space)
J80 hole
approx. 345
approx. 475
FAQ71B
approx. 400
Mounting location
approx. 390
Piping direction
(Required space)
50 or more
Dimensions for
full open front
panel
Outside line
J80 hole
(piping and wiring
intake)
2500 or more
For installation in high
spaces
(Required space)
120 or less
1 Front panel
2 Front grille
3 Air outlet
4 Gas pipe (J15.9 Flare connection)
5 Liquid pipe (J9.5 Flare connection)
6 Drain hoseVP13 (External dia J18)
7 Grounding terminal (M4)
8 Right side piping connection hole
9 Left side drain piping connection hole
Notes:
1 Location of general rated name plate
Right side plate outside surface
2 In case of using infrared remote control,
this position will be a signal receiver.
Refer to the drawing of infrared remote
control in detail.
Name plate
50 or more
Piping direction
Note) 2
Piping direction
(Required space)
3D044897 A
unit (mm)
50 or more
250 or more
(Required space)
J80 hole
approx. 450
approx. 600
FAQ100B
8-5x20 Oval hole (for wood screw)
Mounting location
Detail
j
A
(Mounting hole for installation plate)
approx. 580
Piping direction
(Required space)
50 or more
50 or more
(Required space)
5-6x20 Oval hole (for wood screw)
13-J5 Hole (for wood screw)
2-J12 Hole (for bolt)
(piping and wiring
intake)
Note 2. (service space for air filter)
Direction for air filter draw out
1 Front grille
2 Air filter
3 Discharge outlet
4 Gas piping connection (J15.9 flare)
5 Gas piping connection (J9.5 flare)
6 Drain pipe connection (VP20 O.D. J26)
7 Earth terminal(M4) (inside cover)
8 Slit hole for right side piping connection
9 Slit hole for left side piping connection
Notes:
1 Location of general rated name plate
Right side plate outside surface
2 In case of using infrared remote control, this
position will be a signal receiver. Refer to the
drawing of infrared remote control in detail.
Brand name plate
Ceiling surface
