41
Performance Data
Model: FFQN50CXV1- RYN50CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
340
16°C
21°C 4.84 3.33 1.28 4.67 3.24 1.39 4.49 3.15 1.50 4.31 3.06 1.63 3.96 2.85 1.77 3.66 2.68 1.95
24°C 4.84 3.98 1.28 4.67 3.89 1.39 4.50 3.80 1.50 4.32 3.71 1.63 3.97 3.46 1.77 3.67 3.27 1.95
27°C 4.88 4.52 1.29 4.72 4.41 1.39 4.55 4.31 1.51 4.38 4.20 1.64 4.04 3.91 1.77 3.76 3.67 1.96
30°C 5.03 5.03 1.29 4.89 4.89 1.40 4.74 4.74 1.52 4.59 4.59 1.65 4.25 4.25 1.79 3.98 3.98 1.98
19°C
24°C 5.34 3.11 1.30 5.15 3.03 1.41 4.96 2.95 1.53 4.76 2.86 1.66 4.38 2.67 1.80 4.05 2.51 1.98
27°C 5.34 3.55 1.30 5.15 3.47 1.41 4.96 3.39 1.53 4.77 3.31 1.66 4.38 3.10 1.80 4.05 2.93 1.98
30°C 5.35 4.39 1.30 5.16 4.29 1.41 4.98 4.20 1.53 4.79 4.10 1.66 4.41 3.83 1.80 4.09 3.62 1.99
33°C 5.41 5.41 1.31 5.23 5.23 1.42 5.06 5.06 1.54 4.89 4.89 1.67 4.53 4.53 1.81 4.23 4.23 2.00
22°C
27°C 5.87 3.04 1.33 5.67 2.97 1.44 5.46 2.89 1.56 5.25 2.81 1.69 4.82 2.62 1.84 4.47 2.47 2.02
30°C 5.87 3.70 1.33 5.67 3.63 1.44 5.46 3.54 1.56 5.25 3.46 1.69 4.83 3.24 1.84 4.47 3.07 2.02
33°C 5.87 4.33 1.33 5.67 4.24 1.44 5.46 4.16 1.56 5.25 4.07 1.69 4.83 3.82 1.84 4.48 3.63 2.02
36°C 5.89 4.91 1.33 5.70 4.81 1.44 5.50 4.71 1.56 5.30 4.60 1.70 4.89 4.32 1.84 4.55 4.10 2.03
410
16°C
21°C 5.03 3.47 1.30 4.85 3.38 1.40 4.67 3.29 1.52 4.48 3.20 1.65 4.11 2.98 1.78 3.79 2.80 1.97
24°C 5.05 4.21 1.30 4.87 4.11 1.40 4.68 4.01 1.52 4.50 3.91 1.65 4.13 3.65 1.79 3.82 3.45 1.97
27°C 5.11 4.78 1.30 4.94 4.67 1.41 4.77 4.55 1.52 4.60 4.42 1.65 4.24 4.10 1.79 3.95 3.84 1.98
30°C 5.32 5.32 1.31 5.17 5.17 1.42 5.01 5.01 1.54 4.85 4.85 1.67 4.49 4.49 1.81 4.20 4.20 2.00
19°C
24°C 5.54 3.28 1.32 5.35 3.20 1.43 5.15 3.12 1.54 4.94 3.03 1.67 4.54 2.82 1.82 4.19 2.66 2.00
27°C 5.55 3.78 1.32 5.36 3.70 1.43 5.16 3.61 1.54 4.95 3.53 1.68 4.55 3.30 1.82 4.20 3.12 2.00
30°C 5.58 4.66 1.32 5.39 4.56 1.43 5.19 4.46 1.55 5.00 4.35 1.68 4.60 4.07 1.82 4.27 3.84 2.01
33°C 5.67 5.67 1.32 5.50 5.50 1.43 5.33 5.33 1.56 5.15 5.15 1.69 4.77 4.77 1.83 4.46 4.46 2.03
22°C
27°C 6.09 3.21 1.34 5.88 3.14 1.45 5.66 3.06 1.57 5.43 2.98 1.71 4.99 2.78 1.85 4.62 2.62 2.04
30°C 6.10 3.94 1.34 5.88 3.86 1.45 5.67 3.78 1.58 5.44 3.69 1.71 5.00 3.45 1.85 4.63 3.28 2.04
33°C 6.11 4.62 1.34 5.90 4.53 1.45 5.68 4.44 1.58 5.46 4.35 1.71 5.02 4.08 1.85 4.65 3.87 2.04
36°C 6.15 5.22 1.34 5.95 5.13 1.46 5.74 5.02 1.58 5.53 4.90 1.71 5.11 4.59 1.86 4.76 4.33 2.05
450
16°C
21°C 5.22 3.62 1.31 5.03 3.53 1.41 4.83 3.44 1.53 4.63 3.34 1.66 4.25 3.11 1.80 3.92 2.93 1.98
24°C 5.25 4.40 1.31 5.06 4.29 1.41 4.87 4.19 1.53 4.67 4.08 1.66 4.29 3.81 1.80 3.96 3.59 1.99
27°C 5.33 5.04 1.31 5.16 4.91 1.42 4.98 4.77 1.54 4.80 4.63 1.67 4.44 4.29 1.81 4.14 4.00 2.00
30°C 5.60 5.60 1.32 5.43 5.43 1.43 5.27 5.27 1.55 5.09 5.09 1.69 4.72 4.72 1.83 4.40 4.40 2.02
19°C
24°C 5.74 3.47 1.33 5.54 3.39 1.44 5.33 3.30 1.56 5.11 3.21 1.69 4.69 2.99 1.83 4.33 2.82 2.02
27°C 5.76 4.02 1.33 5.55 3.93 1.44 5.35 3.83 1.56 5.13 3.74 1.69 4.71 3.50 1.83 4.35 3.31 2.02
30°C 5.81 4.94 1.33 5.60 4.84 1.44 5.40 4.73 1.56 5.20 4.61 1.69 4.78 4.30 1.84 4.44 4.06 2.03
33°C 5.93 5.93 1.34 5.76 5.76 1.45 5.58 5.58 1.57 5.40 5.40 1.71 5.00 5.00 1.86 4.68 4.68 2.05
22°C
27°C 6.30 3.40 1.35 6.08 3.32 1.47 5.85 3.24 1.59 5.62 3.15 1.72 5.16 2.94 1.87 4.77 2.78 2.06
30°C 6.32 4.19 1.35 6.09 4.11 1.47 5.86 4.02 1.59 5.63 3.93 1.72 5.17 3.68 1.87 4.78 3.49 2.06
33°C 6.34 4.91 1.35 6.12 4.82 1.47 5.89 4.72 1.59 5.66 4.62 1.73 5.21 4.33 1.87 4.83 4.11 2.06
36°C 6.39 5.54 1.36 6.19 5.44 1.47 5.98 5.32 1.60 5.77 5.19 1.73 5.33 4.84 1.88 4.97 4.56 2.08
Model: FFQN50CXV1- RYN50CXV1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC SC TC SC TC SC TC SC TC SC TC SC TC SC
15°C 3.101 3.101 3.509 3.509 3.646 3.646 5.144 5.144 5.962 5.962 6.371 6.371 6.779 6.779
17°C 3.019 3.019 3.395 3.395 3.566 3.566 5.138 5.138 5.889 5.889 6.299 6.299 6.709 6.709
19°C 2.938 2.938 3.281 3.281 3.486 3.486 5.132 5.132 5.817 5.817 6.228 6.228 6.639 6.639
21°C 2.857 2.857 3.196 3.196 3.407 3.407 5.067 5.067 5.745 5.745 6.157 6.157 6.570 6.570
23°C 2.775 2.775 3.140 3.140 3.327 3.327 4.943 4.943 5.672 5.672 6.086 6.086 6.500 6.500
25°C 2.694 2.694 3.085 3.085 3.248 3.248 4.819 4.819 5.600 5.600 6.015 6.015 6.430 6.430
27°C 2.613 2.613 3.029 3.029 3.168 3.168 4.695 4.695 5.527 5.527 5.944 5.944 6.360 6.360
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
