42
Performance Data
Model: FFQN50CXV1- RYN50CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
340
16°C
21°C 4.98 3.42 1.31 4.80 3.34 1.42 4.62 3.25 1.53 4.44 3.15 1.66 4.08 2.93 1.80 3.76 2.76 1.99
24°C 4.99 4.10 1.31 4.81 4.01 1.42 4.63 3.91 1.53 4.44 3.82 1.66 4.08 3.56 1.81 3.78 3.36 1.99
27°C 5.02 4.65 1.31 4.86 4.54 1.42 4.69 4.44 1.54 4.51 4.32 1.67 4.16 4.02 1.81 3.87 3.78 2.00
30°C 5.18 5.18 1.32 5.03 5.03 1.43 4.88 4.88 1.55 4.72 4.72 1.68 4.38 4.38 1.83 4.09 4.09 2.02
19°C
24°C 5.49 3.20 1.33 5.30 3.12 1.44 5.10 3.03 1.56 4.90 2.95 1.69 4.51 2.75 1.84 4.16 2.59 2.02
27°C 5.49 3.66 1.33 5.30 3.58 1.44 5.11 3.49 1.56 4.91 3.41 1.69 4.51 3.19 1.84 4.17 3.02 2.02
30°C 5.50 4.51 1.33 5.31 4.42 1.44 5.13 4.32 1.56 4.93 4.22 1.69 4.54 3.94 1.84 4.21 3.73 2.03
33°C 5.57 5.57 1.33 5.39 5.39 1.45 5.21 5.21 1.57 5.03 5.03 1.70 4.66 4.66 1.85 4.36 4.36 2.04
22°C
27°C 6.04 3.13 1.35 5.83 3.05 1.47 5.62 2.98 1.59 5.40 2.90 1.73 4.97 2.70 1.87 4.60 2.54 2.06
30°C 6.04 3.81 1.35 5.83 3.73 1.47 5.62 3.65 1.59 5.40 3.56 1.73 4.97 3.33 1.87 4.60 3.16 2.06
33°C 6.05 4.45 1.35 5.84 4.37 1.47 5.62 4.28 1.59 5.41 4.19 1.73 4.97 3.94 1.87 4.61 3.74 2.06
36°C 6.07 5.05 1.36 5.87 4.95 1.47 5.66 4.85 1.59 5.46 4.74 1.73 5.03 4.44 1.88 4.68 4.22 2.07
410
16°C
21°C 5.18 3.57 1.32 4.99 3.48 1.43 4.80 3.39 1.55 4.61 3.29 1.68 4.23 3.07 1.82 3.90 2.88 2.01
24°C 5.20 4.34 1.32 5.01 4.23 1.43 4.82 4.13 1.55 4.63 4.03 1.68 4.25 3.76 1.82 3.93 3.55 2.01
27°C 5.26 4.92 1.33 5.08 4.81 1.43 4.91 4.69 1.55 4.73 4.55 1.69 4.37 4.22 1.83 4.07 3.95 2.02
30°C 5.48 5.48 1.33 5.32 5.32 1.45 5.16 5.16 1.57 4.99 4.99 1.70 4.62 4.62 1.85 4.32 4.32 2.04
19°C
24°C 5.71 3.38 1.34 5.50 3.29 1.45 5.30 3.21 1.58 5.08 3.12 1.71 4.67 2.91 1.85 4.31 2.74 2.04
27°C 5.72 3.89 1.34 5.51 3.81 1.45 5.31 3.72 1.58 5.09 3.63 1.71 4.68 3.40 1.85 4.33 3.21 2.04
30°C 5.74 4.80 1.35 5.54 4.70 1.46 5.35 4.59 1.58 5.14 4.48 1.71 4.73 4.19 1.86 4.39 3.96 2.05
33°C 5.84 5.84 1.35 5.66 5.66 1.46 5.48 5.48 1.59 5.30 5.30 1.72 4.91 4.91 1.87 4.59 4.59 2.07
22°C
27°C 6.27 3.31 1.37 6.05 3.23 1.48 5.82 3.15 1.61 5.59 3.06 1.74 5.14 2.86 1.89 4.75 2.70 2.08
30°C 6.28 4.06 1.37 6.06 3.98 1.48 5.83 3.89 1.61 5.60 3.80 1.74 5.15 3.56 1.89 4.76 3.37 2.08
33°C 6.29 4.76 1.37 6.07 4.67 1.48 5.85 4.57 1.61 5.62 4.47 1.74 5.17 4.20 1.89 4.79 3.98 2.08
36°C 6.33 5.38 1.37 6.12 5.28 1.49 5.91 5.17 1.61 5.70 5.05 1.75 5.25 4.72 1.90 4.90 4.45 2.09
450
16°C
21°C 5.37 3.73 1.33 5.17 3.63 1.44 4.98 3.54 1.56 4.77 3.44 1.69 4.37 3.20 1.83 4.03 3.01 2.02
24°C 5.40 4.53 1.33 5.20 4.42 1.44 5.01 4.31 1.56 4.81 4.20 1.69 4.41 3.92 1.84 4.08 3.70 2.03
27°C 5.49 5.19 1.34 5.31 5.06 1.45 5.13 4.91 1.57 4.94 4.76 1.70 4.57 4.41 1.85 4.26 4.12 2.04
30°C 5.76 5.76 1.35 5.59 5.59 1.46 5.42 5.42 1.59 5.24 5.24 1.72 4.85 4.85 1.87 4.53 4.53 2.06
19°C
24°C 5.91 3.57 1.35 5.70 3.49 1.47 5.48 3.40 1.59 5.26 3.30 1.72 4.83 3.08 1.87 4.46 2.91 2.06
27°C 5.93 4.14 1.36 5.72 4.04 1.47 5.50 3.95 1.59 5.28 3.85 1.72 4.85 3.60 1.87 4.48 3.41 2.06
30°C 5.98 5.09 1.36 5.77 4.98 1.47 5.56 4.86 1.59 5.35 4.74 1.73 4.92 4.43 1.88 4.57 4.18 2.07
33°C 6.11 6.11 1.36 5.93 5.93 1.48 5.75 5.75 1.60 5.56 5.56 1.74 5.15 5.15 1.89 4.81 4.81 2.09
22°C
27°C 6.49 3.50 1.38 6.26 3.42 1.49 6.02 3.33 1.62 5.78 3.25 1.76 5.31 3.03 1.90 4.91 2.86 2.10
30°C 6.50 4.31 1.38 6.27 4.23 1.50 6.03 4.14 1.62 5.79 4.04 1.76 5.32 3.79 1.91 4.92 3.59 2.10
33°C 6.52 5.05 1.38 6.30 4.96 1.50 6.07 4.86 1.62 5.83 4.75 1.76 5.36 4.45 1.91 4.97 4.23 2.10
36°C 6.58 5.70 1.39 6.38 5.60 1.50 6.16 5.48 1.63 5.93 5.34 1.77 5.48 4.98 1.92 5.11 4.69 2.12
Model: FFQN50CXV1- RYN50CXV1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC SC TC SC TC SC TC SC TC SC TC SC TC SC
15°C
3.278 3.278 3.710 3.710 3.854 3.854 5.438 5.438 6.302 6.302 6.735 6.735 7.167 7.167
17°C
3.192 3.192 3.680 3.680 3.770 3.770 5.432 5.432 6.228 6.228 6.662 6.662 7.096 7.096
19°C
3.106 3.106 3.649 3.649 3.686 3.686 5.425 5.425 6.154 6.154 6.589 6.589 7.025 7.025
21°C
3.020 3.020 3.573 3.573 3.603 3.603 5.358 5.358 6.080 6.080 6.517 6.517 6.954 6.954
23°C
2.934 2.934 3.450 3.450 3.519 3.519 5.229 5.229 6.005 6.005 6.444 6.444 6.883 6.883
25°C
2.848 2.848 3.327 3.327 3.435 3.435 5.101 5.101 5.931 5.931 6.371 6.371 6.812 6.812
27°C
2.762 2.762 3.204 3.204 3.352 3.352 4.973 4.973 5.857 5.857 6.299 6.299 6.741 6.741
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
DAIKIN_FFRN.indb 42DAIKIN_FFRN.indb 42 12/27/2012 9:28:13 AM12/27/2012 9:28:13 AM
