Performance Data
Model: FCQN50EXV1 - RYN50CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
430
16°C
21°C 5.05 3.81 1.32 4.87 3.71 1.43 4.69 3.61 1.55 4.50 3.51 1.68 4.14 3.27 1.82 3.82 3.07 2.01
24°C 5.06 4.57 1.32 4.88 4.46 1.43 4.70 4.36 1.55 4.51 4.25 1.68 4.14 3.97 1.82 3.83 3.74 2.01
27°C 5.10 5.10 1.32 4.93 4.93 1.43 4.76 4.76 1.55 4.58 4.58 1.68 4.22 4.22 1.83 3.93 3.93 2.02
30°C 5.26 5.26 1.33 5.11 5.11 1.44 4.95 4.95 1.56 4.79 4.79 1.70 4.44 4.44 1.84 4.16 4.16 2.04
19°C
24°C 5.57 3.56 1.34 5.38 3.47 1.45 5.18 3.38 1.58 4.98 3.28 1.71 4.57 3.06 1.85 4.23 2.88 2.04
27°C 5.58 4.07 1.34 5.38 3.98 1.45 5.18 3.89 1.58 4.98 3.80 1.71 4.58 3.55 1.85 4.23 3.36 2.04
30°C 5.59 5.03 1.34 5.39 4.92 1.45 5.20 4.81 1.58 5.01 4.69 1.71 4.61 4.39 1.86 4.28 4.15 2.05
33°C 5.65 5.65 1.35 5.47 5.47 1.46 5.29 5.29 1.58 5.11 5.11 1.72 4.73 4.73 1.86 4.42 4.42 2.06
22°C
27°C 6.13 3.48 1.37 5.92 3.40 1.48 5.70 3.32 1.61 5.48 3.22 1.74 5.04 3.00 1.89 4.67 2.83 2.08
30°C 6.13 4.25 1.37 5.92 4.16 1.48 5.70 4.06 1.61 5.48 3.97 1.74 5.04 3.71 1.89 4.67 3.52 2.08
33°C 6.14 4.96 1.37 5.92 4.87 1.48 5.71 4.77 1.61 5.49 4.67 1.74 5.05 4.38 1.89 4.68 4.16 2.08
36°C 6.16 5.62 1.37 5.95 5.51 1.48 5.75 5.40 1.61 5.54 5.28 1.75 5.11 4.95 1.89 4.75 4.69 2.09
530
16°C
21°C 5.26 3.98 1.33 5.07 3.88 1.44 4.88 3.77 1.56 4.68 3.67 1.69 4.29 3.41 1.84 3.96 3.21 2.03
24°C 5.27 4.83 1.33 5.08 4.72 1.44 4.89 4.60 1.56 4.70 4.49 1.70 4.31 4.19 1.84 3.99 3.95 2.03
27°C 5.34 5.34 1.34 5.16 5.16 1.45 4.98 4.98 1.57 4.80 4.80 1.70 4.43 4.43 1.85 4.13 4.13 2.04
30°C 5.56 5.56 1.35 5.40 5.40 1.46 5.23 5.23 1.58 5.06 5.06 1.72 4.69 4.69 1.87 4.39 4.39 2.06
19°C
24°C 5.79 3.76 1.36 5.59 3.67 1.47 5.38 3.57 1.59 5.16 3.47 1.72 4.74 3.24 1.87 4.38 3.05 2.06
27°C 5.80 4.33 1.36 5.60 4.24 1.47 5.39 4.14 1.59 5.17 4.04 1.72 4.75 3.78 1.87 4.39 3.58 2.06
30°C 5.83 5.35 1.36 5.63 5.23 1.47 5.43 5.11 1.59 5.22 4.99 1.73 4.81 4.67 1.87 4.46 4.41 2.07
33°C 5.93 5.93 1.36 5.75 5.75 1.48 5.56 5.56 1.60 5.38 5.38 1.74 4.98 4.98 1.89 4.66 4.66 2.09
22°C
27°C 6.37 3.68 1.38 6.14 3.60 1.50 5.91 3.51 1.62 5.68 3.41 1.76 5.22 3.18 1.91 4.83 3.00 2.10
30°C 6.37 4.52 1.38 6.15 4.43 1.50 5.92 4.33 1.62 5.68 4.23 1.76 5.22 3.96 1.91 4.83 3.76 2.10
33°C 6.38 5.30 1.38 6.16 5.20 1.50 5.94 5.09 1.62 5.70 4.98 1.76 5.25 4.67 1.91 4.86 4.44 2.10
36°C 6.42 5.99 1.38 6.22 5.88 1.50 6.00 5.75 1.63 5.78 5.62 1.77 5.33 5.26 1.92 4.97 4.96 2.11
600
16°C
21°C 5.45 4.15 1.34 5.25 4.05 1.45 5.05 3.94 1.57 4.84 3.83 1.71 4.44 3.57 1.85 4.09 3.36 2.04
24°C 5.48 5.04 1.35 5.28 4.92 1.46 5.08 4.80 1.58 4.88 4.68 1.71 4.48 4.36 1.85 4.14 4.12 2.04
27°C 5.57 5.57 1.35 5.39 5.39 1.46 5.21 5.21 1.58 5.02 5.02 1.72 4.64 4.64 1.87 4.32 4.32 2.06
30°C 5.85 5.85 1.36 5.68 5.68 1.48 5.50 5.50 1.60 5.32 5.32 1.74 4.93 4.93 1.89 4.60 4.60 2.08
19°C
24°C 6.00 3.98 1.37 5.78 3.88 1.48 5.57 3.78 1.60 5.34 3.68 1.74 4.90 3.43 1.89 4.52 3.24 2.08
27°C 6.02 4.61 1.37 5.80 4.50 1.48 5.59 4.40 1.60 5.36 4.29 1.74 4.92 4.01 1.89 4.55 3.79 2.08
30°C 6.07 5.67 1.37 5.85 5.55 1.48 5.64 5.42 1.61 5.43 5.28 1.74 5.00 4.93 1.89 4.64 4.64 2.09
33°C 6.20 6.20 1.38 6.02 6.02 1.49 5.83 5.83 1.62 5.64 5.64 1.76 5.23 5.23 1.91 4.89 4.89 2.11
22°C
27°C 6.59 3.89 1.39 6.35 3.81 1.51 6.11 3.71 1.64 5.87 3.62 1.77 5.39 3.37 1.92 4.98 3.19 2.12
30°C 6.60 4.80 1.39 6.36 4.71 1.51 6.13 4.61 1.64 5.88 4.50 1.77 5.40 4.22 1.92 5.00 4.00 2.12
33°C 6.62 5.63 1.39 6.39 5.53 1.51 6.16 5.41 1.64 5.92 5.29 1.78 5.44 4.96 1.93 5.04 4.71 2.12
36°C 6.68 6.35 1.40 6.47 6.24 1.52 6.25 6.10 1.64 6.02 5.95 1.78 5.57 5.55 1.94 5.19 5.19 2.14
Model: FCQN50EXV1 - RYN50CXV1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC SC TC SC TC SC TC SC TC SC TC SC TC SC
15°C
3.075 3.075 3.481 3.481 3.616 3.616 5.103 5.103 5.913 5.913 6.319 6.319 6.724 6.724
17°C
2.995 2.995 3.475 3.475 3.538 3.538 5.096 5.096 5.847 5.847 6.255 6.255 6.662 6.662
19°C
2.914 2.914 3.470 3.470 3.460 3.460 5.090 5.090 5.781 5.781 6.191 6.191 6.601 6.601
21°C
2.834 2.834 3.402 3.402 3.382 3.382 5.029 5.029 5.715 5.715 6.127 6.127 6.539 6.539
23°C
2.753 2.753 3.271 3.271 3.305 3.305 4.913 4.913 5.649 5.649 6.063 6.063 6.477 6.477
25°C
2.672 2.672 3.140 3.140 3.227 3.227 4.797 4.797 5.583 5.583 5.999 5.999 6.415 6.415
27°C
2.592 2.592 3.010 3.010 3.149 3.149 4.682 4.682 5.518 5.518 5.935 5.935 6.353 6.353
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
