44
Performance Data
Model: FCQN60EXV1 - RYN60CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
530
16°C
21°C 6.14 4.34 1.47 5.92 4.23 1.59 5.70 4.11 1.73 5.47 4.00 1.87 5.03 3.72 2.03 4.64 3.50 2.24
24°C 6.15 5.20 1.47 5.93 5.08 1.59 5.71 4.96 1.73 5.48 4.84 1.87 5.04 4.52 2.03 4.66 4.26 2.24
27°C 6.20 5.89 1.48 5.99 5.76 1.60 5.78 5.62 1.73 5.56 5.48 1.88 5.13 5.10 2.04 4.77 4.77 2.25
30°C 6.39 6.39 1.48 6.20 6.20 1.61 6.01 6.01 1.74 5.82 5.82 1.89 5.40 5.40 2.06 5.05 5.05 2.27
19°C
24°C 6.77 4.05 1.50 6.53 3.95 1.62 6.29 3.85 1.76 6.04 3.74 1.90 5.56 3.48 2.07 5.14 3.28 2.28
27°C 6.78 4.64 1.50 6.54 4.53 1.62 6.30 4.43 1.76 6.05 4.32 1.91 5.56 4.04 2.07 5.14 3.83 2.28
30°C 6.79 5.72 1.50 6.55 5.60 1.62 6.32 5.48 1.76 6.08 5.34 1.91 5.60 5.00 2.07 5.19 4.73 2.28
33°C 6.87 6.87 1.50 6.64 6.64 1.63 6.43 6.43 1.76 6.21 6.21 1.91 5.74 5.74 2.08 5.37 5.37 2.30
22°C
27°C 7.45 3.97 1.52 7.19 3.87 1.65 6.93 3.77 1.79 6.66 3.67 1.94 6.12 3.42 2.11 5.67 3.22 2.32
30°C 7.45 4.83 1.52 7.19 4.73 1.65 6.93 4.62 1.79 6.66 4.51 1.94 6.12 4.23 2.11 5.67 4.01 2.32
33°C 7.46 5.65 1.52 7.20 5.54 1.65 6.94 5.43 1.79 6.66 5.32 1.94 6.13 4.99 2.11 5.68 4.74 2.32
36°C 7.48 6.40 1.53 7.23 6.27 1.65 6.98 6.14 1.79 6.73 6.01 1.95 6.20 5.63 2.11 5.77 5.34 2.33
600
16°C
21°C 6.39 4.53 1.49 6.16 4.41 1.61 5.92 4.29 1.74 5.68 4.17 1.89 5.21 3.88 2.05 4.81 3.66 2.26
24°C 6.41 5.50 1.49 6.18 5.37 1.61 5.94 5.24 1.74 5.70 5.11 1.89 5.24 4.76 2.05 4.84 4.50 2.26
27°C 6.48 6.24 1.49 6.27 6.10 1.61 6.05 5.94 1.75 5.83 5.76 1.90 5.38 5.35 2.06 5.02 5.01 2.27
30°C 6.75 6.75 1.50 6.56 6.56 1.63 6.36 6.36 1.76 6.15 6.15 1.92 5.70 5.70 2.08 5.33 5.33 2.30
19°C
24°C 7.04 4.28 1.51 6.79 4.18 1.64 6.53 4.07 1.77 6.27 3.95 1.92 5.76 3.69 2.08 5.32 3.47 2.30
27°C 7.05 4.93 1.51 6.80 4.82 1.64 6.54 4.71 1.77 6.28 4.60 1.92 5.77 4.30 2.09 5.33 4.07 2.30
30°C 7.08 6.09 1.51 6.84 5.95 1.64 6.59 5.82 1.78 6.34 5.68 1.93 5.84 5.31 2.09 5.41 5.02 2.30
33°C 7.20 7.20 1.52 6.98 6.98 1.65 6.76 6.76 1.79 6.53 6.53 1.94 6.05 6.05 2.11 5.66 5.66 2.32
22°C
27°C 7.73 4.19 1.54 7.46 4.09 1.67 7.18 3.99 1.81 6.90 3.88 1.96 6.34 3.62 2.13 5.86 3.42 2.34
30°C 7.74 5.15 1.54 7.47 5.04 1.67 7.19 4.93 1.81 6.90 4.81 1.96 6.35 4.51 2.13 5.87 4.28 2.34
33°C 7.75 6.03 1.54 7.48 5.91 1.67 7.21 5.79 1.81 6.93 5.67 1.96 6.37 5.32 2.13 5.91 5.05 2.35
36°C 7.80 6.82 1.54 7.55 6.69 1.67 7.29 6.55 1.81 7.02 6.40 1.97 6.48 5.98 2.14 6.04 5.65 2.36
680
16°C
21°C 6.62 4.72 1.50 6.38 4.60 1.62 6.14 4.48 1.76 5.88 4.36 1.90 5.39 4.06 2.06 4.97 3.82 2.28
24°C 6.66 5.74 1.50 6.42 5.60 1.62 6.17 5.47 1.76 5.92 5.32 1.91 5.44 4.97 2.07 5.03 4.68 2.28
27°C 6.76 6.58 1.51 6.54 6.41 1.63 6.32 6.23 1.77 6.10 6.04 1.92 5.63 5.59 2.08 5.25 5.22 2.30
30°C 7.10 7.10 1.52 6.90 6.90 1.65 6.68 6.68 1.78 6.46 6.46 1.94 5.98 5.98 2.10 5.59 5.59 2.32
19°C
24°C 7.29 4.53 1.52 7.03 4.42 1.65 6.76 4.31 1.79 6.48 4.19 1.94 5.95 3.91 2.10 5.49 3.68 2.32
27°C 7.31 5.24 1.53 7.05 5.12 1.65 6.78 5.00 1.79 6.51 4.88 1.94 5.98 4.56 2.10 5.52 4.32 2.32
30°C 7.37 6.45 1.53 7.11 6.31 1.65 6.86 6.17 1.79 6.59 6.01 1.94 6.07 5.61 2.11 5.64 5.29 2.33
33°C 7.53 7.53 1.54 7.31 7.31 1.66 7.09 7.09 1.81 6.85 6.85 1.96 6.35 6.35 2.13 5.94 5.94 2.35
22°C
27°C 8.00 4.43 1.55 7.71 4.34 1.68 7.42 4.23 1.82 7.13 4.12 1.98 6.55 3.84 2.14 6.05 3.63 2.36
30°C 8.02 5.46 1.55 7.73 5.36 1.68 7.44 5.24 1.82 7.14 5.12 1.98 6.56 4.80 2.15 6.07 4.55 2.36
33°C 8.04 6.40 1.56 7.77 6.29 1.69 7.48 6.16 1.83 7.19 6.02 1.98 6.61 5.65 2.15 6.12 5.36 2.37
36°C 8.11 7.23 1.56 7.86 7.10 1.69 7.59 6.94 1.83 7.32 6.77 1.99 6.76 6.32 2.16 6.31 5.95 2.38
Model: FCQN60EXV1 - RYN60CXV1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC SC TC SC TC SC TC SC TC SC TC SC TC SC
15°C
3.497 3.497 3.958 3.958 4.112 4.112 5.802 5.802 6.724 6.724 7.185 7.185 7.646 7.646
17°C
3.405 3.405 4.080 4.080 4.016 4.016 5.795 5.795 6.613 6.613 7.071 7.071 7.529 7.529
19°C
3.314 3.314 4.201 4.201 3.921 3.921 5.788 5.788 6.501 6.501 6.956 6.956 7.412 7.412
21°C
3.222 3.222 4.138 4.138 3.825 3.825 5.697 5.697 6.389 6.389 6.842 6.842 7.294 7.294
23°C
3.130 3.130 3.889 3.889 3.730 3.730 5.520 5.520 6.278 6.278 6.727 6.727 7.177 7.177
25°C
3.039 3.039 3.640 3.640 3.634 3.634 5.343 5.343 6.166 6.166 6.613 6.613 7.060 7.060
27°C
2.947 2.947 3.391 3.391 3.539 3.539 5.167 5.167 6.055 6.055 6.498 6.498 6.942 6.942
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
