Si041255EH
Removal Procedure 1
Table of Contents
1. Air Filters .................................................................................................2
2. Front Panel..............................................................................................3
3. Front Grille ..............................................................................................4
4. Horizontal Blades ....................................................................................5
5. Vertical Blade ASSYs..............................................................................6
6. Electrical Box ..........................................................................................7
7. PCBs .......................................................................................................9
8. Swing Motors ........................................................................................12
9. Indoor Heat Exchanger .........................................................................14
10.Fan Motor / Fan Rotor...........................................................................16
Note:
î
The illustrations may be slightly different depending on the model.
