Specifications Si04-306
14 Specifications
220-230-240V, 50Hz / 220-230V, 60Hz
Notes:

MAX. interunit piping length: 30m

MAX. interunit height difference: 20m

Amount of additional charge for piping length exceeding 10m : 20g/m(50/60class), 50g/m(71class)

The data are based on the conditions shown in the table below.
Model
Indoor Units FTKD50BVMA FTKD60BVMA FTKD71BVMA
Outdoor Units RKD50BVMA RKD60BVMA RKD71BVMA
Capacity
Rated (Min.~Max.)
kW 5.2 (0.9~5.9) 6.2 (0.9~7.6) 7.1 (0.9~8.0)
Btu/h 17,750 (3,070~20,140) 21,170 (3,070~22,190) 24,240 (3,070~25,950)
kcal/h 4,470 (770~5,070) 5,330 (770~5,590) 6,110 (770~6,540)
Moisture Removal L/h 2.9 3.9 4.5
Running Current (Rated) A 7.4-7.0-6.7/7.4-7.0 9.6-9.2-8.8/9.6-9.2 11.9-11.4-10.9/11.9-11.4
Power Consumption
Rated (Min.~Max.)
W 1,600 (450~2,300) 2,100 (450~3,210) 2,600 (450~3,350)
Power Factor % 98.3-99.4-99.5/98.3-99.4 99.4-99.2-99.4/99.4-99.2 99.3-99.2-99.4/99.3-99.2
COP W/W 3.25 2.95 2.73
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
φ
9.5
Gas mm
φ
12.7
φ
15.9
φ
15.9
Drain mm
φ
18.0
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Unit FTKD50BVMA FTKD60BVMA FTKD71BVMA
Front Panel Color White White White
Air Flow Rate
m³/min
(cfm)
H 16.8 (593) 17.5 (618) 18.3 (646)
M 14.0 (494) 14.6 (515) 15.3 (540)
L 11.8 (417) 12.2 (431) 12.7 (448)
SL 10.4 (367) 10.8 (381) 11.3 (399)
Fan
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 43 43 43
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof
Running Current (Rated) A 0.19-0.18-0.17/0.19-0.18 0.21-0.20-0.19/0.21-0.20 0.23-0.22-0.21/0.23-0.22
Power Consumption (Rated) W 40 45 50
Power Factor % 95.7-96.6-98.0/95.7-96.6 97.4-97.8-98.7/97.4-97.8 98.8-98.8-99.2/98.8-98.8
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366 337×1,147×366
Weight kg 12 12 12
Gross Weight kg 17 17 17
Operation
Sound
H/M/L/SL dBA 44/40/35/32 45/41/36/33 46/42/37/34
Sound Power H dBA 63 63 63
Outdoor Unit RKD50BVMA RKD60BVMA RKD71BVMA
Casing Color Ivory White Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC32UXD 2YC45ZXD 2YC63ZXD
Motor Output W 1,500 1,900 1,900
Refrigerant Oil
Type SE50P SUNISO 4GSD.I. SUNISO 4GSD.I.
Charge L 0.65 0.75 0.65
Refrigerant
Type R22 R22 R22
Charge kg 1.25 1.80 1.80
Air Flow Rate m³/min (cfm)
H 42.8(1,511) 46.3 (1,634) 51.5 (1,818)
L 40.7(1,437) 42.9 (1,514) 41.5 (1,465)
Fan
Type Propeller Propeller Propeller
Motor Output W 53 53 53
Running Current (Rated) A 7.21-6.82-6.53/7.21-6.82 9.39-9.00-8.61/9.39-9.00 11.67-11.18-10.69/11.67-11.18
Power Consumption (Rated) W 1,560 2,055 2,550
Power Factor % 98.3-99.5-99.5/98.3-99.5 99.5-99.3-99.4/99.5-99.3 99.3-99.2-99.4/99.3-99.2
Starting Current A 6.7 8.8 10.7
Dimensions (H×W×D) mm 735×825×300 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 784×960×390 784×960×390 784×960×390
Weight kg 48 54 56
Gross Weight kg 53 59 61
Operation
Sound
H/L dBA 47/44 49/46 52/49
Sound Power H dBA 63 64 66
Drawing No. 3D040794 3D040795 3D040796
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
