1.2 Cooling Only - R22 Series
220-230-240V, 50Hz / 220-230V, 60Hz
Notes:

MAX. interunit piping length: 30m

MAX. interunit height difference: 20m

Amount of additional charge for piping length exceeding 10m : 20g/m(50/60class), 50g/m(71class)

The data are based on the conditions shown in the table below.
Model
Indoor Units FTKD50BVM FTKD60BVM FTKD71BVM
Outdoor Units RKD50BVM RKD60BVM RKD71BVM
Capacity
Rated (Min.~Max.)
kW 5.2 (0.9~5.9) 6.2 (0.9~6.5) 7.1 (0.9~7.6)
Btu/h 17,750 (3,070~20,140) 21,170 (3,070~22,190) 24,240 (3,070~25,950)
kcal/h 4,470 (770~5,070) 5,330 (770~5,590) 6,110 (770~6,540)
Moisture Removal L/h 2.9 3.9 4.5
Running Current (Rated) A 7.3-7.0-6.7/7.3-7.0 9.6-9.2-8.8/9.6-9.2 11.7-11.2-10.7/11.7-11.2
Power Consumption
Rated (Min.~Max.)
W 1,600 (450~2,300) 2,100 (450~2,700) 2,550 (450~3,210)
Power Factor % 99.6-99.4-99.5/99.6-99.4 99.4-99.2-99.4/99.4-99.2 99.1-99.0-99.3/99.1-99.0
COP W/W 3.25 2.95 2.78
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
φ
9.5
Gas mm
φ
12.7
φ
15.9
φ
15.9
Drain mm
φ
18.0
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Unit FTKD50BVM FTKD60BVM FTKD71BVM
Front Panel Color White White White
Air Flow Rate
m³/min
(cfm)
H 16.8 (593) 17.5 (618) 18.0 (635)
M 14.0 (494) 14.6 (515) 15.1 (533)
L 11.8 (417) 12.2 (431) 12.7 (448)
SL 10.4 (367) 10.8 (381) 11.3 (399)
Fan
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 43 43 43
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof
Running Current (Rated) A 0.19-0.18-0.17/0.19-0.18 0.21-0.20-0.19/0.21-0.20 0.23-0.22-0.21/0.23-0.22
Power Consumption (Rated) W 40 45 50
Power Factor % 95.7-96.6-98.0/95.7-96.6 97.4-97.8-98.7/97.4-97.8 98.8-98.8-99.2/98.8-98.8
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366 337×1,147×366
Weight kg 12 12 12
Gross Weight kg 17 17 17
Operation
Sound
H/M/L/SL dBA 44/40/35/32 45/41/36/33 46/42/37/34
Outdoor Unit RKD50BVM RKD60BVM RKD71BVM
Casing Color Ivory White Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC32UXD 2YC32UXD 2YC45ZXD
Motor Output W 1,500 1,500 1,900
Refrigerant Oil
Type SE50P SE50P SUNISO 4GSD.I.
Charge L 0.65 0.65 0.8
Refrigerant
Type R22 R22 R22
Charge kg 1.25 1.60 1.80
Air Flow Rate m³/min (cfm)
H 42.8(1,511) 46.3 (1,634) 51.5 (1,818)
L 40.7(1,437) 42.9 (1,514) 41.5 (1,465)
Fan
Type Propeller Propeller Propeller
Motor Output W 53 53 53
Running Current (Rated) A 7.11-6.82-6.53/7.11-6.82 9.39-9.00-8.61/9.39-9.00 11.47-10.98-10.49/11.47-10.98
Power Consumption (Rated) W 1,560 2,055 2,500
Power Factor % 99.7-99.5-99.5/99.7-99.5 99.5-99.3-99.4/99.5-99.3 99.1-99.0-99.3/99.1-99.0
Starting Current A 6.7 8.8 10.7
Dimensions (H×W×D) mm 735×825×300 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 784×960×390 784×960×390 784×960×390
Weight kg 48 52 54
Gross Weight kg 53 57 59
Operation
Sound
H/L dBA 47/44 49/46 52/49
Drawing No. 3D040814 3D040815 3D040816
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
