Specifications Si04-306
16 Specifications
220V, 50Hz
Notes:
MAX. interunit piping length: 30m
MAX. interunit height difference: 20m
Amount of additional charge for piping length exceeding 10m :20g/m(18 class), 50g/m(24·28 class)
The data are based on the conditions shown in the table below.
Model
Indoor Units FTKD18BVMS FTKD24BVMS FTKD28BVMS
Outdoor Units RKD18BVMS RKD24BVMS RKD28BVMS
Capacity
Rated (Min.~Max.)
kW 5.2 (0.9~5.8) 6.1 (0.9~7.0) 7.5 (0.9~7.8)
Btu/h 17,700 (3,070~19,800) 20,800 (3,070~23,900) 25,600 (3,070~26,600)
kcal/h 4,470 (770~4,990) 5,250 (770~6,020) 6,450 (775~6,710)
Moisture Removal L/h 2.9 3.9 4.5
Running Current (Rated) A 6.9 8.5 13.7
Power Consumption
Rated (Min.~Max.)
W 1,500 (450~2,300) 1,850 (450~2,900) 2,970 (450~3,270)
Power Factor % 98.8 98.9 98.5
COP (Rated) W/W 3.47 3.30 2.53
Piping
Connections
Liquid mm
φ
6.4
φ
9.5
φ
9.5
Gas mm
φ
15.9
φ
15.9
φ
15.9
Drain mm
φ
18.0
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Unit FTKD18BVMS FTKD24BVMS FTKD28BVMS
Front Panel Color White White White
Air Flow Rate
m³/min
(cfm)
H 17.4 (614) 17.9 (632) 19.0 (671)
M 14.6 (515) 15.0 (530) 15.9 (561)
L 12.2 (431) 12.4 (438) 13.1 (462)
SL 10. 8 (381) 11.0 (388) 11.8 (417)
Fan
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 43 43 43
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof
Running Current A 0.21 0.23 0.24
Power Consumption W 45 50 52
Power Factor % 97.4 98.8 98.5
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366 337×1,147×366
Weight kg 12 12 12
Gross Weight kg 17 17 17
Operation
Sound
H/M/L/SL dBA 45/41/36/33 46/42/37/34 47/43/38/35
Outdoor Unit RKD18BVMS RKD24BVMS RKD28BVMS
Casing Color Ivory White Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC32UXD 2YC45ZXD 2YC63ZXD
Motor Output W 1,500 1,900 1,900
Refrigerant Oil
Type SE50P SUNISO 4GSD.I. SUNISO 4GSD.I.
Charge L 0.65 0.75 0.65
Refrigerant
Type R22 R22 R22
Charge kg 1.60 1.70 1.80
Air Flow Rate m³/min (cfm)
H 46.3 (1,634) 51.5 (1,818) 56.0 (1,977)
L 42.9 (1,514) 41.5 (1,465) 44.5 (1,571)
Fan
Type Propeller Propeller Propeller
Motor Output W 53 53 53
Running Current A 6.69 8.27 13.46
Power Consumption W 1,455 1,800 2,918
Power Factor % 98.9 98.9 98.5
Starting Current A 6.9 8.5 13.7
Dimensions (H×W×D) mm 735×825×300 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 784×960×390 784×960×390 784×960×390
Weight kg 52 54 56
Gross Weight kg 57 59 61
Operation
Sound
H/L dBA 49/46 52/49 52/49
Drawing No. 3D040821 3D040822 3D042234
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
