Si04-306 Specifications
Specifications 23
220-230-240V, 50Hz / 220-230V, 60Hz
Notes:
MAX. interunit piping length: 30m
MAX. interunit height difference: 20m
Amount of additional charge for piping length exceeding 10m : 20g/m(50/60class), 50g/m(71class)
The data are based on the conditions shown in the table below.
Model
Indoor Units FTXD71BVMA
Outdoor Units
RXD71BVMA
Cooling Heating
Capacity
Rated (Min.~Max.)
kW 7.1 (0.9~8.0) 8.5 (0.9~9.7)
Btu/h 24,240 (3,070~27,310) 29,020 (3,070~33,120)
kcal/h 6,110 (770~6,880) 7,310 (770~8,340)
Moisture Removal L/h 4.5 —
Running Current (Rated) A 11.9-11.4-10.9/11.9-11.4 11.8-11.3-10.9/11.8-11.3
Power Consumption
Rated (Min.~Max.)
W 2,600 (450~3,350) 2,580 (450~3,490)
Power Factor % 99.3-99.2-99.4/99.3-99.2 99.4-99.3-98.6/99.4-99.3
COP W/W 2.73 3.29
Piping
Connections
Liquid mm
φ
9.5
Gas mm
φ
15.9
Drain mm
φ
18.0
Heat Insulation Both Liquid and Gas Pipes
Indoor Unit FTXD71BVMA
Front Panel Color White
Air Flow Rate
m³/min
(cfm)
H 18.3 (646) 19.8 (699)
M 15.3 (540) 17.1 (604)
L 12.7 (448) 14.4 (508)
SL 11.3 (399) 12.6 (445)
Fan
Type Cross Flow Fan
Motor Output W 43
Speed Steps 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.23-0.22-0.21/0.23-0.22 0.23-0.22-0.21/0.23-0.22
Power Consumption (Rated) W 50 50
Power Factor % 98.8-98.8-99.2/98.8-98.8 98.8-98.8-99.2/98.8-98.8
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366
Weight kg 12
Gross Weight kg 17
Operation
Sound
H/M/L/SL dBA 46/42/37/34 46/42/37/34
Sound Power H dBA 63 63
Outdoor Unit RXD71BVMA
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC63ZXD
Motor Output W 1,900
Refrigerant
Oil
Model SUNISO 4GSD.I.
Charge L 0.75
Refrigerant
Model R22
Charge kg 1.80
Air Flow Rate
(H/L)
m³/min 51.5/41.5 41.9/37.4
cfm 1,818/1,465 1,479/1,320
Fan
Type Propeller
Motor Output W 53
Running Current (Rated) A 11.67-11.18-10.69/11.67-11.18 11.57-11.08-10.69/11.57-11.08
Power Consumption (Rated) W 2,550 2,530
Power Factor % 99.3-99.2-99.4/99.3-99.2 99.4-99.3-98.6/99.4-99.3
Starting Current A 11.3
Dimensions (H×W×D) mm 735×825×300
Packaged Dimensions (H×W×D) mm 784×960×390
Weight kg 57
Gross Weight kg 61
Operation
Sound
H/L dBA 52/49 52/49
Sound Power H dBA 66 66
Drawing No. 3D040792
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
