Si04-306 Specifications
Specifications 25
220V, 60Hz
Notes:

MAX. interunit piping length: 30m

MAX. interunit height difference: 20m

Amount of additional charge for piping length exceeding 10m: 20g/m(50/60 class), 50g/m(71 class)

The data are based on the conditions shown in the table below.
Model
Indoor Units FTXD71BVMT
Outdoor Units
RXD71BVMT
Cooling Heating
Capacity (Min.~Max.)
kW 0.9~7.6 0.9~9.0
kcal/h 775~6,540 775~7,740
Moisture Removal L/h 4.5 —
Running Current A 14.0 12.6
Power Consumption (Min.~Max.) W 470~3,210 470~3,600
Power Factor % 99.0 99.2
COP W/W 2.48 3.09
Piping
Connections
Liquid mm
φ
9.5
Gas mm
φ
15.9
Drain mm
φ
18.0
Heat Insulation Both Liquid and Gas Pipes
Indoor Unit FTXD71BVMT
Front Panel Color White
Air Flow Rate m³/min (cfm)
H 16.6 (585) 18.2 (642)
M 13.9 (490) 15.7 (553)
L 11.7 (412) 13.3 (469)
SL 10.4 (368) 11.7 (412)
Fan
Type Cross Flow Fan
Motor Output W 43
Speed Steps 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof
Running Current A 0.23 0.23
Power Consumption W 50 50
Power Factor % 98.8 98.8
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366
Weight kg 12
Gross Weight kg 17
Operation
Sound
H/M/L/SL dBA 46/42/37/34 46/42/37/34
Outdoor Unit RXD71BVMT
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC45ZXD
Motor Output W 1,900
Refrigerant
Oil
Model SUNISO 4GSD.I.
Charge L 0.75
Refrigerant
Model R22
Charge kg 1.80
Air Flow Rate m³/min (cfm)
H 51.5 (1,818) 41.9 (1,479)
L 41.5 (1,465) 37.4 (1,320)
Fan
Type Propeller
Motor Output W 53
Running Current A 13.77 12.37
Power Consumption W 3,000 2,700
Power Factor % 99.0 99.2
Starting Current A 14.0
Dimensions (H×W×D) mm 735×825×300
Packaged Dimensions (H×W×D) mm 784×960×390
Weight kg 55
Gross Weight kg 59
Operation
Sound
H/L dBA 52/49 52/49
Drawing No. 3D040810A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 21°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
