6
English
Read Before Operation
Outdoor Unit
• The appearance of the outdoor unit may differ between different models.
Open the front panel
Air fi lter
Refrigerant piping and inter-
unit wiring
Earth terminal (inside)
Drain hose
Air outlet
Model name plate
Air inlet
(back and side)
Outdoor temperature
sensor (back)
Titanium apatite deodorizing
fi lter (without frame)
Model name
plate
Names of Parts
■ FTX20K2V1B / FTX25K2V1B / FTX35K2V1B / FTX20K5V1B / FTX25K5V1B / FTX35K5V1B
■ FTXP20K2V1B / FTXP25K2V1B / FTXP35K2V1B
■ FTXP20K3V1B / FTXP25K3V1B / FTXP35K3V1B
To Next Page
