Read Before Operation
Display
Air inlet
Front panel
Air outlet
Louvers (vertical blades)
• The louvers are inside of the air
outlet.
Flap (horizontal blade)
Indoor temperature
sensor
• Detects the air temperature
around the unit.
OPERATION lamp (green)
TIMER lamp (orange)
Signal receiver
• Receives signals from the remote
controller.
• When the unit receives a signal, you
will hear a beep sound.
Case Sound type
Operation start beep-beep
Setting changed beep
Operation stop long beep
Indoor unit ON/OFF switch
• Press this switch once to start operation.
Press once again to stop it.
• For the operation mode setting, refer to the following table.
Mode Temperature setting Airfl ow rate
AUTO 25°C AUTO
• This switch can be used when the remote controller is missing.
Names of Parts
Indoor Unit
• The appearance of the indoor unit may differ between different models.
