Daikin FTXF-C - 6 Unit Installation; 6.1 Installation Site Preparation; 6.1.1 Site Requirements

6 | Unit installation
Installer reference guide
24
FTXF20~42C5V1B + ATXF20~42C5V1B
Daikin room air conditioner
4P519439-9J – 2021.06
6 Unit installation
In this chapter
6.1 Preparing the installation site ................................................................................................................................................ 24
6.1.1 Installation site requirements of the indoor unit .................................................................................................. 24
6.2 Opening the indoor unit ......................................................................................................................................................... 25
6.2.1 To remove the front panel..................................................................................................................................... 25
6.2.2 To re-install the front panel ................................................................................................................................... 26
6.2.3 To remove the front grille...................................................................................................................................... 26
6.2.4 To re-install the front grille .................................................................................................................................... 27
6.2.5 To remove the electrical wiring box cover ............................................................................................................ 27
6.2.6 To open the service cover...................................................................................................................................... 27
6.3 Installing the indoor unit ........................................................................................................................................................ 28
6.3.1 Precautions when installing the indoor unit.......................................................................................................... 28
6.3.2 To install the mounting plate................................................................................................................................. 28
6.3.3 To drill a wall hole .................................................................................................................................................. 28
6.3.4 To remove the pipe port cover.............................................................................................................................. 29
6.3.5 To provide drainage ............................................................................................................................................... 29
6.1 Preparing the installation site
Choose an installation location with sufficient space for carrying the unit in and out
of the site.
Do NOT install the unit in places often used as work place. In case of construction
works (e.g. grinding works) where a lot of dust is created, the unit MUST be
covered.
WARNING
The appliance shall be stored in a room without continuously operating ignition
sources (example: open flames, an operating gas appliance or an operating electric
heater).
WARNING
Make sure installation, servicing, maintenance and repair comply with instructions
from Daikin and with applicable legislation and are executed ONLY by authorised
persons.
6.1.1 Installation site requirements of the indoor unit
INFORMATION
Also read the precautions and requirements in the "2 General safety
precautions"[46].
INFORMATION
The sound pressure level is less than 70dBA.
▪ Air flow. Make sure nothing blocks the air flow.
▪ Drainage. Make sure condensation water can be evacuated properly.
▪ Wall insulation. When conditions in the wall exceed 30°C and a relative humidity
of 80%, or when fresh air is inducted into the wall, then additional insulation is
required (minimum 10mm thickness, polyethylene foam).
