Si04-858 Removal of Air Filter
Removal Procedure 3
3
Lift an air filter upwards
slightly and then pull it
out downwards.
The right and left air filters
are interchangeable.
Insert the air filters along
grooves when installing.
When installing, insert 2
hooks of the air filter
completely.
3. Remove the air-purifying
filter.
The right and left air-
purifying filters are
interchangeable.
1
Titanium Apatite Photo-
catalytic Air-purifying
Filter is fixed on the rear
of the air filter.
2
Bend the air filter to
release the protrusions
and remove the
Titanium Apatite
Photocatalytic Air-
Purifying filter.
Step
Procedure Points
(R5005)
(R5006)
Titanium Apatite Photocatalytic
Air-purifying Filter
(R3763)
(R3764)
To Next Page
