SiBE041102_A Outdoor Unit

Removal Procedure 133

Remove the protection

bushing.

Remove the electronic

expansion valve coil.

Remove the putty.

Step

Procedure Points

Protection bushing

(R14530)

Electronic expansion

valve coil

(R14531)

(R14532)
