Notes on flaps and louvers angles
"
To adjust the vertical blades (louvers)
Hold the knob and move the louvers.
(You will find a knob on the left-side and the right-side blades.)
• When “
SWING button
” is selected, the flaps swinging range depends
on the operation mode. (See the figure.)
"
ATTENTION
• Always use a remote control to adjust the flaps angle. If you attempt to
move it forcibly with hand when it is swinging, the mechanism may be
broken.
• Be careful when adjusting the louvres. Inside the air outlet, a fan is
rotating at a high speed.
.
