Instruction SiENBE12-713
164 System Configuration
CAUTION
Care and cleaning
FTK(X)S 50/60/71 F
CAUTION
Before cleaning, be sure to stop the operation and turn the breaker OFF.
UNITS
"
Indoor unit, Outdoor unit and Remote control
1. Wipe them with dry soft cloth.
"
Front panel
1. Open the front panel.
• Hold the panel by the tabs on the two sides
and lift it until it stops with a click.
2. Remove the front panel.
• Open the front panel further while sliding it to
either the left or right and pulling it toward
you. This will disconnect the rotation dowel
on one side. Then disconnect the rotation
dowel on the other side in the same manner.
3. Clean the front panel.
• Wipe it with a soft cloth soaked in water.
• Only neutral detergent may be used.
• In case of washing the grille with water, dry it
with cloth, dry it up in the shade after
washing.
4. Attach the front panel.
• Align the rotation dowels on the left and right
of the front panel with the slots, then push
them all the way in.
• Close the front panel slowly.
(Press the panel at both sides and the
center).
• Don’t touch the metal parts of the indoor unit. If you touch those parts, this may cause an injury.
• When removing or attaching the front grille, use a robust and stable stool and watch your steps carefully.
• When removing or attaching the front grille, support the grille securely with hand to prevent it from falling.
• For cleaning, do not use hot water above 40 °C, benzine, gasoline, thinner, nor other volatile oils, polishing compound,
scrubbing brushes, nor other hand stuff.
• After cleaning, make sure that the front grille is securely fixed.
