Daikin FTXS24LVJU - Service Manual

Other manuals for Daikin FTXS24LVJU

Engineering Data661 pages

Operation Manual42 pages

Installation Manual14 pages

Questions and Answers

S
stacy83Aug 18, 2025
What to do if the operation lamp is blinking on my Daikin Air Conditioner?
- D
  Diana SosaAug 18, 2025
  If the operation lamp on your Daikin Air Conditioner is blinking, you should first perform the diagnostic procedure. Also, ensure all indoor units connected to a multi-system outdoor unit are set to the same operation mode. If they aren't, set all indoor units to the same operation mode and check if the operation lamp stops blinking. You can also try setting all indoor units to cooling or heating mode to see if the operation lamp returns to normal.
C
chad79Aug 20, 2025
What to do if my Daikin Air Conditioner cooling (heating) effect is poor?
- C
  chenmarkAug 20, 2025
  If your Daikin Air Conditioner isn't cooling or heating effectively, check the following: * Ensure the air filters are clean. * Make sure nothing is blocking the air inlet or outlet of either the indoor or outdoor units. * Verify the temperature setting is appropriate. * Confirm that all windows and doors are closed. * Check that the airflow rate and direction are correctly set.
A
Abigail FloresAug 23, 2025
What to do if my Daikin FTXS24LVJU operation stopped suddenly?
- K
  Kevin CrawfordAug 23, 2025
  If your Daikin Air Conditioner stops suddenly and the OPERATION lamp flashes, check the following: * Ensure the air filters are clean. * Confirm that nothing is blocking the air inlet or outlet of the indoor and outdoor units. * Turn the breaker off, remove any obstructions, and then turn it back on. Try operating the air conditioner with the remote controller. * If you have a multi-system, verify that all indoor units are set to the same operation mode. If not, set them all to the same mode and check if the lamps flash. * If the operation mode is in “AUTO”, set all indoor unit operation modes to “COOL” or “HEAT” for a moment and check again that the lamps are normal.
K
Kelly TorresAug 26, 2025
What to do if my Daikin FTXS24LVJU does not operate and the OPERATION lamp is off?
- A
  Amanda EllisAug 26, 2025
  If your Daikin Air Conditioner isn't operating and the OPERATION lamp is off, check the following: * See if a breaker is off or a fuse has blown. * Check for a power failure. * Ensure batteries are correctly installed in the remote controller. * Verify that the timer setting is correct.
H
Heidi BarnesAug 28, 2025
What to do if Daikin Air Conditioner stops suddenly and the operation lamp blinks?
- W
  William WilliamsAug 28, 2025
  If the Daikin Air Conditioner operation stops suddenly and the operation lamp blinks, it might be due to an operation mode conflict. Ensure all indoor units connected to the multi-system outdoor unit are set to the same operation mode. If they aren't, change them to the same mode and see if the blinking stops. If the mode is set to automatic, try setting all indoor units to either cooling or heating and check again.
P
Patricia AndersonAug 30, 2025
Why does mist come out of my Daikin Air Conditioner indoor unit?
- M
  Marissa GrayAug 30, 2025
  Mist coming from the indoor unit of your Daikin Air Conditioner can occur for two reasons: * During COOL operation, room air may be cooled into mist by the cold airflow. * During defrosting, the air in the room is cooled by the heat exchanger and becomes mist.
A
aschultzSep 2, 2025
Why Daikin FTXS24LVJU Air Conditioner hot air does not flow out soon after the start of HEAT operation?
- R
  Robert ParksSep 2, 2025
  If hot air doesn't flow out immediately after starting HEAT operation on your Daikin Air Conditioner, it's likely because the unit is warming up. Please wait for 1 to 4 minutes.
A
Ashley VazquezSep 4, 2025
Why does Daikin FTXS24LVJU indoor unit gives out odor?
- E
  Edwin DrakeSep 4, 2025
  If your Daikin Air Conditioner's indoor unit emits an odor, it's likely due to smells from the room, furniture, or cigarettes absorbed into the unit and discharged with the airflow. If this occurs, have the indoor unit cleaned by a technician from the service shop where you bought the air conditioner.
J
Jonathan YoungSep 6, 2025
How to fix Daikin FTXS24LVJU when HEAT operation cannot be selected?
- E
  Emma NortonSep 7, 2025
  If you cannot select HEAT operation on your Daikin Air Conditioner, even though it's a heat pump model, slide the DIP switch to the left as shown in the illustration so that the HEAT operation can be selected with the “MODE” button.
R
Robert ClineSep 9, 2025
Why is the operation lamp blinking on my Daikin FTXS24LVJU Air Conditioner?
- N
  nicholasmartinSep 9, 2025
  The operation lamp on your Daikin Air Conditioner might be blinking because a protection device in either the indoor or outdoor unit has been activated, or the thermistor is malfunctioning. It could also indicate a signal transmission error between the indoor and outdoor units.

Summary

Daikin Inverter Pair Air Conditioners

FTXS-L & FDXS-L Series Service Manual

Comprehensive service manual for Daikin Inverter Pair air conditioners, covering FTXS-L and FDXS-L series.

Daikin FTXS Series Functions and Specifications

FTXS Series Functions List

Detailed list of operational functions and features for Daikin FTXS series indoor and outdoor units.

FTXS Series Technical Specifications

Detailed technical specifications for Daikin FTXS series models, including capacity, power, and dimensions.

Daikin FDXS Series Functions and Specifications

FDXS Series Functions List

Detailed list of operational functions and features for Daikin FDXS series indoor and outdoor units.

FDXS Series Technical Specifications

Detailed technical specifications for Daikin FDXS series models, including capacity, power, and dimensions.

Daikin Air Conditioner Wiring and PCB Diagrams

Indoor Unit Wiring Diagrams and PCBs

Wiring diagrams and PCB component layouts for Daikin indoor units (FTXS, FDXS series).

Outdoor Unit Wiring Diagrams and PCBs

Wiring diagrams and PCB component layouts for Daikin outdoor units (RXS, RKS series).

Daikin Air Conditioner Functionality and Control

Core Air Conditioner Functions

Explanation of key functions like temperature control, frequency principles, and automatic operation modes.

Control Specifications and Protection

Details on control specifications, mode hierarchy, frequency control, and protective functions.

Daikin Air Conditioner Operation Manual

FTXS Series Operation Guide

Instructions for operating Daikin FTXS series air conditioners using the remote controller and various modes.

FDXS Series Operation Guide

Instructions for operating Daikin FDXS series air conditioners using the remote controller and various modes.

Daikin Air Conditioner Service Diagnosis and Troubleshooting

Troubleshooting with Operation Lamps and LEDs

Guide to troubleshooting Daikin AC units by observing operation lamps and LED indicators.

Daikin AC Error Codes and Fault Finding

Comprehensive guide to Daikin AC error codes and systematic troubleshooting procedures for common faults.

Daikin Air Conditioner Component Removal Procedures

Indoor Unit Component Removal

Step-by-step guide for removing internal components of Daikin FTXS and FDXS series indoor units.

Outdoor Unit Component Removal

Step-by-step guide for removing internal components of Daikin RXS and RKS series outdoor units.

Daikin AC Trial Operation and Field Settings

Performing Daikin AC Trial Operation

Procedures for conducting trial operation and verifying system performance after installation.

Configuring Daikin AC Field Settings

Instructions for setting model type, temperature display, and facility-specific operational parameters.

Daikin AC Manual Appendix

Refrigerant Piping Diagrams

Schematic diagrams illustrating the refrigerant piping for Daikin indoor and outdoor units.

Electrical Wiring Diagrams

Detailed electrical wiring diagrams for Daikin indoor and outdoor units, including PCB layouts.

Daikin FTXS24LVJU Specifications

General

Cooling Capacity	24000 BTU/h
Energy Efficiency Ratio (EER)	11.5
HSPF	10.0
Refrigerant	R32
Type	Split
Heating Capacity	24000 BTU/h
Power Supply	230V/50Hz
Indoor Unit Weight	9 kg
