Si041251EC
Fan
Rotor
Remo
val P
roced
ure
21
7
Remove the screw of
the lef
t si
de plat
e.
8
Unfast
en the 2 hooks
and remove the
left
si
de
plate.
9
Press t
he bearing f
rom
the outs
ide and r
emove
the beari
ng.
Step
Procedure
Points
(R4414)
Left side
plate
(R4415)
Hook
Hook
Bearing
(R4416)
22
24
