Si041251EC
Removal Procedure 1
Table of Contents
1. Air Filters .................................................................................................2
2. Front Panel..............................................................................................3
3. Front Grille ..............................................................................................4
4. Horizontal Blades / Vertical Blade ASSYs ..............................................5
5. Electrical Box ..........................................................................................7
6. PCBs .......................................................................................................9
7. Drain Pan Unit / Swing Motor................................................................13
8. Fan Motor..............................................................................................15
9. Indoor Heat Exchanger .........................................................................17
10.Fan Rotor ..............................................................................................20
Note:
î
The illustrations may be slightly different depending on the model.
