Daikin FTXV41UVLT - Names of Parts

ON/OFF
5
Display
Air inlet
Front panel
Air outlet
Louvres (vertical blades)
• Thelouvresareinsideoftheair
outlet.
Page 12
Flaps (horizontal blades)
Page 12
Model name
Room temperature
sensor and Room
humidity sensor.
• Itsensestheairtemperature
andhumidityaroundtheunit.
INTELLIGENT EYE
sensor
• Itdetectsthemovementsof
peopleandautomatically
switchesbetweennormal
operationandenergysaving
operation.
Page 14,15
TIMER lamp (orange)
Page 20,21
OPERATION lamp (green)
INTELLIGENT EYE lamp
(green) :
Page 14
Signal receiver
• Receivessignalsfromtheremote
controller.
• Whentheunitreceivesasignal,you
willhearabeepsound.
Case Sound type
Operationstart beep-beep
Settingchanged beep
Operationstop longbeep
Indoor unit ON/OFF switch
• Pressthisswitchoncetostartoperation.
Pressonceagaintostopit.
• Fortheoperationmodesetting,refertothefollowingtable.
Mode Temperature setting Airow rate
AUTO 25°C AUTO
• Thisswitchcanbeusedwhentheremotecontrollerismissingoroutof
batteries.
Names of Parts
Indoor Unit
 FTXV41/50/60/71
