Outdoor Unit
 Open the front panel
Air  lter
Deodorizing  lter
(enzyme blue)
 RXV41/50
 RXV60/71
Refrigerant pipes and
inter-unit wire
Earth terminal (inside)
Drain hose
Air outlet
Air inlet
(back and side)
Outdoor temperature
sensor (back)
Outdoor temperature
sensor (back)
Air inlet
(back and side)
Refrigerant pipes and
inter-unit wire
Earth terminal (inside)
Drain hose
Air outlet
