Names of parts
■ Indoor Unit
■ Opening the Front Panel
How to open the front panel: (page 28.)
CAUTION
12
6
5
2
4
7
8
3
9
12
10
11
13
14
Air outlet selection switch
This setting blows air from upper outlet only.•
This setting automatically decides a blow
pattern depending on mode and conditions.
•
• The unit is shipped from the
factory with this setting.
• This setting is
recommended.
Before opening the front panel, be sure to stop the operation and turn the breaker OFF.
Do not touch the metal parts on the inside of the indoor unit, as it may result in injury.
