10
FXHQ-MVJU EDUS39-600A-F5
FXHQ12-36MVJU
ELECTRICALCOMPONENTSANDWIRINGCONNECTORSFORINDOORUNIT
A1P PRINTEDCIRCUITBOARD
C1 CAPACITOR(M1F)
F1U
FUSE(
B
5A,250V)
HAP LIGHTEMITTINGDIODE(SERVICEMONITOR-GREEN)
KAR MAGNETICRELAY(M1S)
KPR MAGNETICRELAY
M1F MOTOR(INDOORFAN)
M1S MOTOR(SWINGFLAP)
Q1M THERMOSWITCH(M1FEMBEDDED)
R1T THERMISTOR(AIR)
R2T THERMISTOR(COILLIQUID)
R3T THERMISTOR(COILGAS)
S1Q LIMITSWITCH(SWINGFLAP)
T1R TRANSFORMER(208-230V/25V)
V1TR TRIAC
X1M TERMINALBLOCK(POWER)
X2M TERMINALBLOCK(CONTROL)
Y1E ELECTRONICEXPANSIONVALVE
RECEIVER/DISPLAYUNIT(ATTACHEDTOWIRELESSREMOTECONTROLLER)
A2P PRINTEDCIRCUITBOARD
A3P PRINTEDCIRCUITBOARD
BS1 PUSHBUTTON(ON/OFF)
H1P LIGHTEMITTINGDIODE(ON-RED)
H2P LIGHTEMITTINGDIODE(TIMER-GREEN)
H3P LIGHTEMITTINGDIODE(FILTERSIGN-RED)
H4P LIGHTEMITTINGDIODE(DEFROST-ORANGE)
SS1 SELECTORSWITCH(MAIN/SUB)
SS2 SELECTORSWITCH(WIRELESSADDRESSSET)
CONNECTORFOROPTIONALPARTS
X18A CONNECTOR(WIRINGADAPTORFORELECTRICALAPPENDICES)
X23A CONNECTOR(WIRELESSREMOTECONTROLLER)
C:3D048116C
