5. Wiring Diagrams
C: 3D048116C
NOTES)
1. : TERMINAL BLOCK , : CONNECTOR : SHORT CIRCUIT CONNECTOR
2. : FIELD WIRING
3. IN CASE USING CENTRAL REMOTE CONTROLLER, CONNECT IT TO THE UNIT IN ACCORDANCE WITH THE ATTACHED INSTRUCTION MANUAL.
4. X23A IS CONNECTED WHEN THE WIRELESS REMOTE CONTROLLER KIT IS BEING USED.
5. WHEN CONNECTING THE INPUT WIRES FROM OUTSIDE, FORCED OFF OR ON/OFF CONTROL OPERATION CAN BE SELECTED BY REMOTE
CONTROLLER. IN DETAILS, REFER TO THE INSTALLATION MANUAL ATTACHED THE UNIT.
6. SYMBOLS SHOW AS FOLLOWS.
(BLU: BLUE BLK: BLACK ORG: ORANGE PNK: PINK RED: RED WHT: WHITE YLW: YELLOW)
7. USE COPPER CONDUCTORS ONLY.
8. CLASS 2 WIRE
