Daikin FXHQ-MVJU - Electric Characteristics

11
FXHQ-MVJU EDUS39-600A-F5
6. Electric Characteristics
FXHQ12-36MVJU
Model
Powersupply IFM Input(W)
SCCR
Hz Volts Voltagerange MCA MOP KW FLA Cooling Heating
FXHQ12MVJU
60 208/230 V
Max.253V
Min.187V
0.8 15 0.062 0.6 90 90
SCCRkArms,
Symmetrical
@600VMAX:5
FXHQ24MVJU 1.0 15 0.130 0.8 127 127
FXHQ36MVJU 1.4 15 0.130 1.1 161 161
Symbol:
MCA: MinimumCircuitAmpacity(A)
MOP: MaximumOvercurrentProtectiveDevice(A)
KW: FanMotorRatedOutput(kW)
FLA: FullLoadAmpacity(A)
IFM: IndoorFanMotor
SCCR:Short-CircuitCurrentRating
Note:
1.Voltagerange
Unitsaresuitableforuseonelectricalsystemswherevoltagesuppliedtounitterminalsisnotbeloworabovelistedrangelimits.
2.Maximumallowablevoltageunbalancebetweenphaseis2%.
3.MCA/MOP
MCA=1.25×FLA
MOP≤4×FLA
(Nextlowerstandardfuseraring.Minimum15A)
4.SelectwiresizebasedonthevalueofMCA.
5.Eitherafuseoracircuitbreakerisacceptable.
C:4D049333B
