WARNING
• Request the dealer or an authorized technician to install the product.
Improper installation of the product could result in water leakage, an electric shock, or re.
• The product must be installed according to the instructions given in this manual.
The Incomplete installation of the product could result in water leakage, an electric shock, or re.
•
Use of other parts could result in the unit becoming loose and falling, water leakage, electric shock, or re.
•
Touching any electrical parts with the power supply turned on could result in electric shock.
•
Wires connected or xed improperly could result in terminal overheating, an electric shock, or re.
• When wiring and connecting the indoor and outdoor units, carefully arrange the wiring so that they will not put improper force on the
structures.
Install covers over the wires. Incomplete cover installation could result in terminal overheating, an electric shock, or re.
ACCESSORIES
Read these Safety Considerations carefully before installing the drain pan heater. After completing the installation, check
if the unit operates properly during the start-up operation.
Drain Pan Heater 1 1 1
M4 piercing screw 3 6
6
Binding band 1 1 1
Sealing Material 1 2 2
Installation Manual
(multi-language)
Electric Wiring
Diagram Label
1 1 1
Information Label 1 1 1
TOOLS REQUIRED
• Electric Drill
• ɸ1/8 inch (ɸ3.2mm) drill
• Phillips Screwdriver
• Nippers
To Next Page
