Figure 7 continued: Service Menu – Keypad/Display Menu Structure
See page 67
Modbus Status
SF MB Status=_________
RF/EF MB Status=______
ER MB Status=________
OF MB Status= ________
IFB MB Status= ________
D3 MB Status=_________
SAFVFD Ex Flt= _______
RxFVFD Ex Flt= _______
ER VFD Ex Flt= ________
OF VFD Ex Flt= ________
MB Resistance= Yes
ECM Cong= Done
See page 67
D3 Status
D3 Comm Sts= ________
D3 Addr Err= __________
D3 On/Off= ___________
D3 Mode= ____________
D3 Clg Spt= XXX.XºF
D3 Htg Spt= XXX.XºF
D3 Fan Spd= __________
D3 Min Load= XXX%
D3 Max Load= XXX%
D3 Eco Ena= __________
OA Enthalpy= XXXBTU/lb
OA Hum Ratio= g/kg
D3 SWVers= XXXXXXXXXX
OAAdd1–16= __________
OAAdd17–32= _________
OAAdd33–49= _________
OAAdd50–64= _________
SetOAAddr= XX
CurrOAAddr= XX
CurrOAAmps= XXXA
CurrOARLA= XXXA
See page 68
Sensor Offsets
Disch Air= 0.0ºF
Return Air= 0.0ºF
Space Temp= 0.0ºF
OA Temp= 0.0ºF
EF/LC Temp= 0.0ºF
EW Temp= 0.0ºF
Mixed Air= 0.0ºF
MAT LON SCC= 0.0ºF
ER LAT= 0.0ºF
ER EAT= 0.0ºF
Sump Temp= 0.0ºF
DRT1= 0.0ºF
DRT3= 0.0ºF
SRT= 0.0ºF
DFT= 0.0ºF
IRT= 0.0ºF
ORT= 0.0ºF
See page 66
Network Input Status
Net OAT In= XXX.XºF
Net Space In= XXX.XºF
NetCurrState= _________
NetNextState= _________
NetTmToNxtSt= XXXXXmin
Net App Mode= ________
Net Cl Ena Sw= X.X
Net Cl Ena VI= XXX%
Net Ht Ena Sw= X.X
Net Ht Ena VI= XXX%
Net Ec Ena Sw= X.X
Net Ec Ena VI= XXX%
Net SAF Cap= XXX%
Net RAF Cap= XXX%
Net ExhF Cap= XXX%
Net CFlw Sw= XXX%
Net Flw Val= XXX%
Net Space IAQ= XXXXPPM
Net Rel Humid= XXX%
Net DATClgSpt= XXX.XºF
Net DATHtgSpt= XXX.XºF
nviSetpoint= XXX.XºF
OccManCmd= _________
Net Min OA= XXX%
nvoEffSpt= XXX.XºF
nciOccClgSpt= XXX.XºF
nciOccHtgSpt= XXX.XºF
nciHVACType= _________
See page 62 – 68
Service Menus
Timer Settings
►
Operating Hours
►
Save/Restore Settings
►
Active Alarms
►
Alarm Log
►
Alarm Conguration
►
Analog Input Status
►
Universal I/O Status
►
Digital Input Status
►
Digital Output Status
►
Network Input Status
►
Modbus Status
►
D3 Input Status
►
Sensor Offsets
►
Reset Counte= XXXX
OM 920-6 • MICROTECH UNIT CONTROLLER 18 www.DaikinApplied.com
