Daikin MicroTech III Sales And Engineering Data Sheet

ED 15103-6 • MICROTECH III WSHP UNIT CONTROLLER 18 www.DaikinApplied.com
ComprehensIve daTa Tables
Table 9: Analog Values - SmartSource Single and Two Stage, Ennity Large Two Compressor, Continued
Point Name
Object
Type/
Instance
Read/
Write
Access
2
BACnet Object
Name
Range/Default
(in Units)
Non-
volatile
Memory
1
Description
ANALOG VALUES
Compressor #1
Runtime Totalizer
AV:40 W
CompRunHours
SmartSource
(Series2)
Comp1RunHours
Ennity Large Two
Compressor (SS2C)
0 to 65535
Hours
Default: 0
Y
Total compressor (Series2) or compressor #1 (SS2C)
runtime hours.
8
Compressor #1 Starts
Totalizer
AV:41 W
CompStarts
SmartSource
(Series2)
Comp1Starts
Ennity Large Two
Compressor (SS2C)
0 to 65535
Starts
Default: 0
Y
Total compressor (Series2) or compressor #1 (SS2C)
starts.
8
Compressor #2
Runtime Totalizer
AV:42 W
CompHiCap
RunHours
SmartSource
(Series2)
Comp2RunHours
Ennity Large Two
Compressor (SS2C)
0 to 65535
Hours
Default: 0
Y
Total compressor high capacity (Series2) or compressor #2
(SS2C) runtime hours.
8
Compressor #2 Starts
Totalizer
AV:43 W
CompHiCapStarts
SmartSource
(Series2)
Comp2Starts
Ennity Large Two
Compressor (SS2C)
0 to 65535
Starts
Default: 0
Y
Total compressor high capacity (Series2) or compressor #2
(SS2C) starts.
8
MAC Address /
Address Switch
AV:411
W
MacAddress
(S3 Address Switch
set to 255 - factory
default setting)
1 to 127 Y
The function of AV411 depends on the setting of the
BACnet communication module physical Address Switch
(S3). When the physical address switch is set to a value
of 255, the dynamic MAC addressing algorithm is used
to commission the BACnet communication module. This
variable represents the unit’s MAC Address that can be
written through the network or through the conguration
serial port. When the physical address switch is not set
to a value of 255, it represents the setting of the physical
address switch and is read-only.
R
MacAddressSwitch
(S3 Address Switch
not physically set
to 255)
System Minimum
Instance
4,5
AV:412 W SystemMinInstance
0 to 4194302
Default: 3101000
Y
This value is added to the MAC Address to determine the
nal BACnet Device Name and Device Instance Number.
Example: the default Device Instance Number = 3101007
when the MAC = 7.
Table 10: Binary Inputs - SmartSource Single and Two Stage, Ennity Large Two Compressor
Point Name
Object
Type/
Instance
Read/
Write
Access
2
BACnet Object
Name
Range/Default
(in Units)
Non-
volatile
Memory
1
Description
ANALOG VALUES
Binary Input Status BI:1 R
BinaryIn
(Description
Property)
32 bits N
Monitors the digital inputs of the unit controller for
diagnostic purposes. Each item is reported as a bit so
that multiple inputs can be viewed simultaneously. The
Present_Value reects the rst status bit (b0), which is the
“Normal / Service-Test Mode Jumper” state.
All the status bits are returned in the BI1.description
property, high bit on the left and low bit on the right.
Example: 00000000000000000000000000000001 indicates
that the Normal / Service-Test jumper input is true. See
Selected Parameters Information for bit descriptions.
