ED 15103-6 • MICROTECH III WSHP UNIT CONTROLLER 38 www.DaikinApplied.com
ComprehensIve daTa Tables
Table 19: Network Variable Outputs (NVOs) - SmartSource Single and Two Stage Compressor and Ennity Large Two
Compressor, Continued
Point Name
lonWorks Variable
(NV Index
2
)
SNVT Type
(SNVT Index)
Range/
Default
(in Units)
Heart-
beat
Description
Network Variable Outputs (NVOs)
Compressor #1
Suction Temperature
nvoSuctionTemp1
(41)
SNVT_temp_p
(105)
0 to 158ºF
17.77 to 70ºC
Default
1
:
621.806ºF
327.67ºC
No
Indicates the compressor #1 suction line temperature sensor
value.
1
Compressor #2
Suction Temperature
nvoSuctionTemp2
(SS2C: 42)
SNVT_temp_p
(105)
0 to 158ºF
17.77 to 70ºC
Default
1
:
621.806ºF
327.67ºC
No
Indicates the compressor #2 suction line temperature sensor
value.
1
Applies only to Ennity Large Two Compressor (SS2C) units.
Condensate Overow
Status
nvoCondOverow
(30)
SNVT_switch
(95)
Default: Null No
Monitors the Condensate Overow sensor input.
Selection State Value
Dry 0 0%
Wet 1 100%
Null -1 0 to 100%
Current Alarm
nvoCurrentAlarm
(31)
SNVT_str_asc
(36)
Init: No Alarms No
Displays the current highest active alarm.
SmartSource (Series2) Alarm Strings
• No Alarms
• IO Exp Communication Fail
• Invalid Conguration
• Low Voltage Brownout
• Comp High Pressure
• Comp Low Pressure
• Comp Suctn Temp Snsr Fail
• Comp Low Suction Temp
• Freeze Fault Detect
• Room Temp Sensor Fail
• Entering Water Temp Snsr Fail
• Leaving Water Temp Snsr Fail
• Condensate Overow
• Low Entering Water Temp
• Serial EEPROM Corrupted
• Wtrside Econ Low Temp Cutout
Ennity Large Two Comp (SS2C) Alarm Strings
• No Alarms
• IO Exp Communication Fail
• Invalid Conguration
• Low Voltage Brownout
• Comp #1 High Pressure
• Comp #2 High Pressure
• Comp #1 Low Pressure
• Comp #2 Low Pressure
• Comp #1 Suctn Temp Snsr Fail
• Comp #2 Suctn Temp Snsr Fail
• Comp #1 Low Suction Temp
• Comp #2 Low Suction Temp
• Freeze Fault Detect
• Room Temp Sensor Fail
• Entering Water Temp Snsr Fail
• Leaving Water Temp Snsr Fail
• Condensate Overow
• Low Entering Water Temp
• Serial EEPROM Corrupted
• Wtrside Econ Low Temp Cutout
Discharge Air
Temperature
nvoDischAirTemp
(32)
SNVT_temp_p
(105)
0 to 158ºF
17.77 to 70ºC
Default
1
:
621.806ºF
327.67ºC
Send Indicates the Discharge Air Temperature sensor value.
1
1. Analog Null (0x7FFF) is a discrete temperature value of 621.806ºF/327.67ºC. Its purpose is to indicate a sensor failure condition or when the unit controller is not
using that temperature value.
2. The Network Variable index number is a unique identier for certain LonWorks variables. Some BAS companies use this numeric value instead of text to
reference these variables. The NV index number can also be found in the XIF le.
3. After Receive Heartbeat is enabled, this variable reverts to the default (non-override) value if it is not refreshed often enough through a network command or if
communication is disabled (i.e. the device is disabled or is ofine).
4. The totalizer continues to increment until the maximum count is reached, at which point the BAS must reset the value by issuing a write command. The variable is
saved in nonvolatile memory every 24 hours. If power is lost, that day’s totalizer information is not stored.
