Daikin RCS 06F Installation Manual

30 IM 962-2
Warranty Registration Form
To comply with the terms of D
aikin Applied Warranty, complete and return this Equipment
Warranty Registration Form within 10 days to Daikin Applied, Warranty Department.
Check, test, and start procedure for RoofPak roof mounted air conditioners with or without heat recovery and roof
mounted air handlers.
Job Name:________________________________________
Daikin G.O. No.: _________________
Installation address: __________________________________________________________________________________________________
City: ______________________________________________________________________________ State: __________________________
Purchasing contractor: ________________________________________________________________________________________________
City: ______________________________________________________________________________ State: __________________________
Name of Person doing start-up (print)____________________________________________________________________________________
Company name _____________________________________________________________________________________
Address ___________________________________________________________________________________________
City/State/Zip_______________________________________________________________________________________
Unit model number: ________________________________________________ Unit serial number: _______________________________
Compressor #1 model number: ______________________ Serial number: ___________________________________
Serial number: ___________________________________
Compressor #2 model number: ______________________
Circle Yes or No. If not applicable to the type of unit, circle N/A.
I. INITIAL CHECK
A. Is any shipping damage visible? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
B. Tightened all setscrews? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
C. Have the shipping spacers been removed from the compressor springs and have the neoprene spacers been
installed on each compressor mounting bolt? (Only applies to 115C-135C units with compressor spring isolators.)?
Yes No N/A
D. Electrical service corresponds to unit nameplate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
Volts __________ Hertz __________ Phase __________
E. Is the main disconnect adequately fused and are fuses installed? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
F. Are crankcase heaters operating, and have they been operating 24 hours prior to start-up? . . . . . . . . . . . . . . . . . . . . Yes No N/A
G. Are all electrical power connections tight (Check compressor electrical box.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
H. Has the field piping been piped per ASHRAE recommendations? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
II. START-UP COMPRESSOR OPERATION
A. Has each circuit been field leak tested? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
B. Circuit 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
C. Circuit 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
D. Refrigerant charge per circuit: Circuit 1 _______ Circuit 2 _______
E. Do condenser fans rotate in the right direction?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
F. Are compressors rotating in the right direction?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
G. Ambient temperature: ______________°F
H. Compressor lockout timers function? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
I. Does unit start up and perform per sequence of operation?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
III. PERFORMANCE DATA
A. Compressor voltage across each phase:
L1-2________ V L2-3 ________ V
L1-3 _______ V
B. Compressor amperage of fully loaded compressor:
Compressor #1: Phase 1 ________ Phase 2 ________ Phase 3 ________
Compressor #2: Phase 1 ________ Phase 2 ________ Phase 3 ________
C. Low pressure cut-out: Circuit 1 psig Circuit 2 psig
Low pressure cut-in: Circuit 1 psig Circuit 2 psig
D. High pressure cut-out: Circuit 1 psig Circuit 2 psig
E. Discharge pressure, one compressor: Circuit 1 psig Circuit 2 psig
F. Discharge pressure, fully loaded: Circuit 1 psig Circuit 2 psig
G. Suction pressure, one compressor: Circuit 1 psig Circuit 2 psig
Suction pressure, fully loaded: Circuit 1 psig Circuit 2 psig
Liquid press, fully loaded
(at liquid line shut-off valve):
Circuit 1 psig Circuit 2
psig
Liquid temperature, fully loaded: Circuit 1 psig Circuit 2 psig
Circuit 1 Circuit 2
H. Suction Line temperature: °F
°F
I. Superheat: °F
°F
Please see the following page "Quality Assurance Survey Report" and list any additional comments that could affect the operation of this unit; e.g.,
shipping damage, failed components, adverse installation applications, etc. If additional comment space is needed, write the comment(s) on a
separate sheet, attach it to the Survey Report and return it to the Warranty Department with the above completed Warranty Registration form.
RETURN COMPLETED EQUIPMENT WARRANTY REGISTRATION FORM TO:
Daikin McQuay Warranty Department, 13600 Industrial Park Boulevard, Minneapolis, MN 55441
J. Supercooling: °F
°F
K. Is the liquid in the liquid line sightglass clear and dry?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
L. At what suction pressure does the hot gas bypass valve open? Circuit 1________ psig Circuit 1________ psig
M. Record discharge air temperature at discharge of the air handler: °F
N. Are all control lines secure to prevent excessive vibration and wear? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
O. Are all gauges shut off and valve caps and packings tight after start-up? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
Signature: ______________________________________________________ Start-up date:____________________________________
