Condenser and Compressor Piping
Figure 12: B-Cabinet Condenser Piping, Compressors, 1 to 2 Compressors per Circuit are Provided
Splitter Solenoid
(optional)
Comp 1
Comp 3
Comp 2
Comp 4
To DX
Coil
Filter Dryer (replaceable core optional)
shown)
Ckt 1
Ckt 2
Liquid Line Sight Glass
Suction Shut-off Valve (optional)
Hot gas Bypass
Valves and Liquid
Line solenoids
(not shown)
Optional Refrigerant
Temperature and Pressure
Transducers
NOTE: Unit with 4 xed-speed compressors shown.
