www.DaikinApplied.com 143 IM 1287-6 • REBEL APPLIED ROOFTOP
Ventilation and Flue Pipe Requirements
CAUTION
Prevent snow levels from blocking airow into the furnace vestibule and
combustion air inlet. Ensure snow does not accumulate and interfere with
the operation of electronics within the vestibule.
WARNING
Connect this unit only to gas supplied by a commercial utility. This furnace
must be installed by an experienced professional installation company
that employs fully trained and experienced technicians. Failure to connect
gas lines to proper connection points may result in injury, death, and
property damage. Install the gas piping in accordance with local codes
and regulations of the installing utility company. In the absence of local
codes, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or the
CSA B149.1, Natural Gas and Propane Installation Code — latest edition.
CAUTION
Sharp edges on sheet metal, fasteners, clips and similar items may cause
personal injury. Exercise caution when installing or servicing the unit
and wear appropriate personal protective equipment (PPE), such as eye
protection, gloves, protective clothing, footwear, etc.
DANGER
Keep hands and tools away to prevent electrical shock. Failure to adhere
to this warning can result in serious injury or death. LOCKOUT/TAGOUT
all power sources prior to starting the spark ignitor and ignition controller.
WARNING
Fire or Explosion Hazard
Failure to follow warnings exactly could result in serious injury, death,
or property damage. Be sure to read and understand the installation,
operation, and service instructions within this manual. Improper installation,
adjustments, alterations, service, or maintenance can cause serious injury,
death or property damage.
— Do not store or use gasoline or other ammable
vapors or liquids in the vicinity of this appliance
— What to do if you smell gas
• Do not try to light any product that is fueled by or
contains an open ame
• Do not touch any electrical switch
• Do not use any telephone in the building
• Leave the building immediately
• Immediately call the gas supplier from a remote
telephone and follow the gas supplier’s instructions
• If you cannot reach the gas supplier, call the local re
department or 911
— Installation and service must be performed by a
qualied installer, service agency, or gas supplier
WARNING
Risque D’Incedie ou D`Explosion
Le non respect des mises en garde pourrait entrainer des blessures graves,
la mort ou des pertes materielles. Prendre soin de lire et de comprendre les
instructions d’installation, de fonctionement et d’entretien contenues dans
ce guide. Une installatoin, un reglage, une modication, une reparation ou
un entretien inapproprie peut entrainer des blessures graves, la mort ou
des pertes materielles.
— Ne pas entreposer ni utiliser d’essence ou autre
vapeurs ou liquides inammables a proximite de cet
appareil ou de tout autre appareil.
— QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE
GAZ
• Ne tentez pas d’alumer un appareil.
• Ne touchez pas a un interupteur; n’utilisez pas de
telephone dan l’edice ou vous trouvez.
• Sortez de l’edice immediatement.
• Appelez immediatement le fournisseurde gas a partir
d’un telephone a l’exterieur de l’edice. Suivez les
instructions du fournisseur de gaz.
• Si vous ne pouvez joindre le fournisseur de gaz,
appelez les pompiers.
— L’installation et les reparations doivent etre conees
a un installateur qualie ou au fournisseur de gaz.
The Rebel Applied rooftop unit is equipped with a louvered
furnace access door to supply adequate combustion
Installation
1. Inspect the gas furnace module upon arrival for any
damage that may have occurred during shipping.
2. Locate rating plate and verify that the furnace fuel
supply and power requirements are met at the point of
installation.
Electrical Requirements
All electrical equipment must be grounded and wired in
accordance with the National Electric Code (ANSI/NFPA 70)
in the US and the Canadian Electric Code (CSA C22.1) in
Canada as well as any codes of the local jurisdiction in which
the equipment is installed. If any original wire supplied with the
appliance must be replaced, it must be replaced with wiring
material having a temperature rating of at least 90°C / 194°F
and VW-1 ammability classication requirement.
Flue Installation
Flue assemblies are shipped secured to the interior of the
supply fan section. Remove ues from shipping straps by
removing the bolts securing the strap to the upstream side of
the furnace vestibule. Straps may be discarded while strap
hardware should be reinstalled in their respective holes. Return
to the furnace section and remove ue blank o plates. Retain
hardware and use to mount ues to ue openings.
