Operating Procedures
WARNING
Fire or Explosion Hazard
LOCKOUT/TAGOUT all power sources prior to installing the gas furnace.
Failure to follow warnings exactly could result in serious injury, death,
or property damage. Be sure to read and understand the installation,
operation, and service instructions within this manual. Improper installation,
adjustments, alterations, service, or maintenance can cause serious injury,
death or property damage.
— Do not store or use gasoline or other ammable
vapors or liquids in the vicinity of this appliance.
— What to do if you smell gas
• Do not try to light any product that is fueled by or
contains an open ame.
• Do not touch any electrical switch.
• Do not use any telephone in the building.
• Leave the building immediately.
• Immediately call the gas supplier from a remote
telephone and follow the gas supplier’s instructions.
• If you cannot reach the gas supplier, call the local re
department or 911.
— Installation and service must be performed by a
qualied installer, service agency, or gas supplier.
WARNING
Risque D’Incedie ou D`Explosion
Le non respect des mises en garde pourrait entrainer des blessures graves,
la mort ou des pertes materielles. Prendre soin de lire et de comprendre les
instructions d’installation, de fonctionement et d’entretien contenues dans
ce guide. Une installatoin, un reglage, une modication, une reparation ou
un entretien inapproprie peut entrainer des blessures graves, la mort ou
des pertes materielles.
— Ne pas entreposer ni utiliser d’essence ou autre
vapeurs ou liquides inammables a proximite de cet
appareil ou de tout autre appareil.
— QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE
GAZ
• Ne tentez pas d’alumer un appareil.
• Ne touchez pas a un interupteur; n’utilisez pas de
telephone dan l’edice ou vous trouvez.
• Sortez de l’edice immediatement.
• Appelez immediatement le fournisseurde gas a partir
d’un telephone a l’exterieur de l’edice. Suivez les
instructions du fournisseur de gaz.
• Si vous ne pouvez joindre le fournisseur de gaz,
appelez les pompiers.
— L’installation et les reparations doivent etre conees
a un installateur qualie ou au fournisseur de gaz.
WARNING
Replace and/or tighten all plugs removed or loosened when adjusting gas
pressure. Leak test the ttings using a commercially available soap solution
made specically for the detection of leaks to check all connections. Failure
to follow this warning could result in an explosion, re, severe personal
injury, death, or property damage.
WARNING
Never test for gas leaks with an open ame. Testing with an open ame
can cause can cause an explosion or re resulting in property damage,
personal injury, or death. Use a commercially available soap solution made
specically for the detection of leaks to check all connections.
Burner and Gas Manifold Pressure Adjustment
Rebel Applied gas furnaces are available in a variety of staged
and modulating congurations. Reference Table 41 on page
154 to identify the pressure required at the various locations
shown in Figure 206 on page 150 based on furnace input
capacity and modulation range. Follow the directions in the
burner and gas manifold instructions section below based on
modulation capacity.
