IM 1287-6 • REBEL APPLIED ROOFTOP 8 www.DaikinApplied.com

Figure 5: ECM Fan Array Identication
2X3
1M
2M 3M
4M 5M
6M
2X2
1M
2M
3M4M
1X2
1M
2M
1X1
1M
NOTE: MicroTech unit controller will communicate via modbus for M-marked fans.
