RELQ-TATJA / TAYDA / TAYCA EDUS371705C-D
RELQ96-120TAYDA
A1P PRINTED CIRCUIT BOARD (MAIN) R12T THERMISTOR (COMP. SUCTION)
A2P PRINTED CIRCUIT BOARD (NOISE FILTER) R13T THERMISTOR (RECEIVER GAS PURGE)
A3P PRINTED CIRCUIT BOARD (INV) R14T THERMISTOR (M1C BODY)
A4P, A5P PRINTED CIRCUIT BOARD (FAN) R15T THERMISTOR (LEAK DETECTION)
A6P PRINTED CIRCUIT BOARD (SUB) R16T THERMISTOR (EVT)
A7P PRINTED CIRCUIT BOARD (ABC I/P) R21T THERMISTOR (M1C DISCHARGE)
BS1~BS3 PUSH BUTTON SWITCH (A1P) (MODE, SET, RETURN) R71T THERMISTOR (POWER MODULE) (A3P)
C48, C51 CAPACITOR (A3P) R72T THERMISTOR (DIODE) (A3P)
C404 CAPACITOR (A2P) S1NPH PRESSURE SENSOR (HIGH)
DS1, DS2 DIP SWITCH (A1P) S1NPL PRESSURE SENSOR (LOW)
E1HC, E2HC
CRANKCASE HEATER S1PH PRESSURE SWITCH (HIGH)
F1U FUSE (A1P, A3P, A6P)
SEG1~SEG3
7-SEGMENT DISPLAY (A1P)
F2U FUSE (A1P) T1A CURRENT SENSOR
F101U FUSE (A4P, A5P) T1R TRANSFORMER (460 V / 230 V)
F404U FUSE (A2P) V1D DIODE (CURRENT LIMITING) (A3P)
F410U, F412U
FUSE (A2P) V1R DIODE BRIDGE
HAP
PILOTLAMP (A1P, A3P~A6P) (SERVICE MONITOR-GREEN)
V1R POWER MODULE (A4P, A5P)
K1M MAGNETIC CONTACTOR V2R POWER MODULE (A3P)
K3R MAGNETIC RELAY (A3P) X1A, X2A CONNECTOR (M1F)
K3R MAGNETIC RELAY (Y1S) (A1P) X3A, X4A CONNECTOR (M2F)
K4R MAGNETIC RELAY (Y2S) (A1P) X5A CONNECTOR (CHECK THE RESIDUAL CHARGE)
K6R MAGNETIC RELAY (OPTION) (A1P) X6A, X7A CONNECTOR (T1R)
K7R MAGNETIC RELAY (E1HC, E2HC) (A1P)
X13A, X14A
CONNECTOR (E1HC, E2HC)
K8R MAGNETIC RELAY (Y7S) (A1P) X1M TERMINAL BLOCK (POWER SUPPLY)
K9R MAGNETIC RELAY (Y4S) (A1P) X1M TERMINAL BLOCK (CONTROL) (A1P)
K11R MAGNETIC RELAY (Y3S) (A1P) X1M TERMINAL BLOCK (ABC I/P) (A7P)
K12R MAGNETIC RELAY (Y5S) (A1P) Y1E ELECTRIC EXPANSION VALVE (HEAT EXC. UPPER)
K13R MAGNETIC RELAY (Y6S) (A1P) Y2E ELECTRIC EXPANSION VALVE (SUBCOOL HEAT EXC.)
K84R MAGNETIC RELAY (A3P) Y3E ELECTRIC EXPANSION VALVE (HEAT EXC. LOWER)
L1R REACTOR Y4E ELECTRIC EXPANSION VALVE (INJECTION)
M1C MOTOR (COMPRESSOR) Y5E
ELECTRIC EXPANSION VALVE (REFRIGERANT COOLING)
M1F, M2F MOTOR (FAN) Y6E
ELECTRIC EXPANSION VALVE (LEAK DETECTION)
PS SWITCHING POWER SUPPLY (A1P, A3P, A6P) Y7E
ELECTRIC EXPANSION VALVE (RECEIVER GAS PURGE)
Q1LD LEAKAGE DETECTION CIRCUIT (A1P) Y1S SOLENOID VALVE (OS OIL RETURN 1)
R1 RESISTOR (CURRENT LIMITING) (A3P) Y2S SOLENOID VALVE (HOT GAS BYPASS)
R24 RESISTOR (CURRENT SENSOR) (A4P, A5P) Y3S SOLENOID VALVE (LIQUID SHUT OFF)
R131, R133
RESISTOR (A3P) Y4S 4 WAY VALVE (HP/LP GAS)
R401 RESISTOR (CURRENT SENSOR) (A3P) Y5S 4 WAY VALVE (HEAT EXC. LOWER)
R1T THERMISTOR (AIR) Y6S 4 WAY VALVE (HEAT EXC. UPPER)
R3T THERMISTOR (RECEIVER INLET) Y7S SOLENOID VALVE (ACCUMU OIL RETURN)
R4T THERMISTOR (HEAT EXC. LIQUID UPPER) Z1C~Z3C NOISE FILTER (FERRITE CORE)
R5T THERMISTOR (HEAT EXC. LIQUID LOWER) ZF NOISE FILTER (A2P) (WITH SURGE ABSORBER)
R6T THERMISTOR (SUBCOOL GAS) CONNECTOR FOR OPTIONAL ACCESSORIES
R7T THERMISTOR (SUBCOOL LIQUID) X37A CONNECTOR (POWER ADAPTER) (A1P)
R8T THERMISTOR (HEAT EXC. GAS UPPER) COOL/HEAT SELECTOR
R9T THERMISTOR (HEAT EXC. GAS LOWER) S1S SELECTOR SWITCH (FAN/COOL·HEAT)
R10T THERMISTOR (SUCTION) S2S SELECTOR SWITCH (COOL/HEAT)
R11T THERMISTOR (DEICER)
C: 2D112583D
