RELQ-TATJA / TAYDA / TAYCA EDUS371705C-D
RELQ72-120TAYCA
A1P PRINTED CIRCUIT BOARD (MAIN) R12T THERMISTOR (COMP. SUCTION)
A2P, A3P PRINTED CIRCUIT BOARD (NOISE FILTER) R13T THERMISTOR (RECEIVER GAS PURGE)
A4P PRINTED CIRCUIT BOARD (INV) R14T THERMISTOR (M1C BODY)
A5P, A6P PRINTED CIRCUIT BOARD (FAN) R15T THERMISTOR (LEAK DETECTION)
A7P PRINTED CIRCUIT BOARD (SUB) R16T THERMISTOR (EVT)
A8P PRINTED CIRCUIT BOARD (ABC I/P) R21T THERMISTOR (M1C DISCHARGE)
BS1~BS3 PUSH BUTTON SWITCH (A1P) (MODE, SET, RETURN) S1NPH PRESSURE SENSOR (HIGH)
C1 CAPACITOR (A4P) S1NPL PRESSURE SENSOR (LOW)
DS1, DS2 DIP SWITCH (A1P) S1PH PRESSURE SWITCH (HIGH)
E1HC, E2HC
CRANKCASE HEATER
SEG1~SEG3
7-SEGMENT DISPLAY (A1P)
F1U FUSE (A1P, A4P, A7P) T1A CURRENT SENSOR
F2U FUSE (A1P) T1R TRANSFORMER (575 V / 220 V)
F101U FUSE (A2P, A5P, A6P) V1D DIODE (A4P)
F100U,
F104U, F105U
FUSE (A2P)
V1R POWER MODULE (A4P)
V1R POWER MODULE (A5P, A6P)
F1UT THERMAL FUSE (A4P) V1T TRANSISTOR (A4P)
HAP
PILOTLAMP (A1P, A4P~A7P) (SERVICE MONITOR-GREEN)
X1A, X2A CONNECTOR (M1F, M2F)
K1M MAGNETIC CONTACTOR (A4P) X5A CONNECTOR (CHECK THE RESIDUAL CHARGE)
K3R MAGNETIC RELAY (Y1S) (A1P) X3A, X4A CONNECTOR (T1R)
K4R MAGNETIC RELAY (Y2S) (A1P)
X13A, X14A
CONNECTOR (E1HC, E2HC)
K6R MAGNETIC RELAY (OPTION) (A1P) X1M TERMINAL BLOCK (POWER SUPPLY)
K7R MAGNETIC RELAY (E1HC, E2HC) (A1P) X1M TERMINAL BLOCK (CONTROL) (A1P)
K8R MAGNETIC RELAY (Y7S) (A1P) X1M TERMINAL BLOCK (ABC I/P) (A8P)
K9R MAGNETIC RELAY (Y4S) (A1P) Y1E ELECTRIC EXPANSION VALVE (HEAT EXC. UPPER)
K11R MAGNETIC RELAY (Y3S) (A1P) Y2E ELECTRIC EXPANSION VALVE (SUBCOOL HEAT EXC.)
K12R MAGNETIC RELAY (Y5S) (A1P) Y3E ELECTRIC EXPANSION VALVE (HEAT EXC. LOWER)
K13R MAGNETIC RELAY (Y6S) (A1P) Y4E ELECTRIC EXPANSION VALVE (INJECTION)
L1R REACTOR Y5E
ELECTRIC EXPANSION VALVE (REFRIGERANT COOLING)
M1C MOTOR (COMPRESSOR) Y6E ELECTRIC EXPANSION VALVE (LEAK DETECTION)
M1F, M2F MOTOR (FAN) Y7E
ELECTRIC EXPANSION VALVE (RECEIVER GAS PURGE)
PS SWITCHING POWER SUPPLY (A1P, A4P, A7P) Y1S SOLENOID VALVE (OS OIL RETURN 1)
Q1LD LEAKAGE DETECTION CIRCUIT (A1P) Y2S SOLENOID VALVE (HOT GAS BYPASS)
R1 RESISTOR (CURRENT LIMITING) (A4P) Y3S SOLENOID VALVE (LIQUID SHUT OFF)
R2 RESISTOR (CURRENT SENSOR) (A4P, A5P, A6P) Y4S 4 WAY VALVE (HP/LP GAS)
R1T THERMISTOR (AIR) Y5S 4 WAY VALVE (HEAT EXC. LOWER)
R3T THERMISTOR (RECEIVER INLET) Y6S 4 WAY VALVE (HEAT EXC. UPPER)
R4T THERMISTOR (HEAT EXC. LIQUID UPPER) Y7S SOLENOID VALVE (ACCUMU OIL RETURN)
R5T THERMISTOR (HEAT EXC. LIQUID LOWER) Z1C~Z3C NOISE FILTER (FERRITE CORE)
R6T THERMISTOR (SUBCOOL GAS) ZF NOISE FILTER (A2P, A3P) (WITH SURGE ABSORBER)
R7T THERMISTOR (SUBCOOL LIQUID) CONNECTOR FOR OPTIONAL ACCESSORIES
R8T THERMISTOR (HEAT EXC. GAS UPPER) X37A CONNECTOR (POWER ADAPTER) (A1P)
R9T THERMISTOR (HEAT EXC. GAS LOWER) COOL/HEAT SELECTOR
R10T THERMISTOR (SUCTION) S1S SELECTOR SWITCH (FAN/COOL·HEAT)
R11T THERMISTOR (DEICER) S2S SELECTOR SWITCH (COOL/HEAT)
C: 2D112579D
