Daikin REQ100B7W1B - Page 18

• Outdoor Units • R-410A • REQ-B7
• Split Sky Air • Outdoor Units
16
37
4
4 Capacity tables
4 - 2 Heating capacity tables
FCQ71-125B7V3B + REQ71-100B7V3B
REQ71-125B7W1B
Heating capacity table
Outdoor
Indoor outdoor temperature (°CWB)
EDB -10 -5 0 6 10 15
(°C) TC PI TC PI TC PI TC PI TC PI TC PI
3TW26592-5
SYMBOLS
AFR: Air flow rate (m
3
/min)
EDB: Entering dry bulb temp. (°CDB)
WB: Wet bulb temperature (°CWB)
TC: Total cooling/heating capacity (kW)
PI: Power input (kW)
(comp.+indoor+outdoor fan motor)
Caution:
TC is shown by kW
V3: 230 V [50 Hz]
W1: 400 V [50 Hz]
NOTES
1. Ratings shown are net capacities.
Influence of fan motor heat is included.
2.
Shows nominal capacities
3. Capacities are based on following conditions:
* outdoor air : 85 % RH. however, the condition on nominal capacity
is 7° CDB/6° CWB
* Corresponding refrigerant piping length : 7.5 m
Level difference : 0 m
4. Direct interpolation is permissible.
Do not extrapolate.
5. Air flow rate and BF are tabulated below.
Model FCQ
71
AFR 18
BF 0.1
100
AFR 28
BF 0.16
125
AFR 31
BF 0.07
6. Add the following corrections to power input of each model.
Model Supply FCQ
71
V3 0.06
W1 0
100
V3 0.09
W1 0
125 W1 0
