Daikin REQ100B7W1B - External connection diagram

• Outdoor Units • R-410A • REQ-B7
• Split Sky Air • Outdoor Units
26
37
7
7 Wiring diagram
7 - 2 External connection diagram
4TW26329-7
REQ71∼125B7
Field wire
Symbol explication
I = Pair
II = Twin
III = Triple
M = Master
S = Slave
1 = Earth leak detector
2 = Fuse
3 = Remote control
