• Split Sky Air • Outdoor Units
5
• Outdoor Units • R-410A • REQ-B7
2 Specifications
2-2 ELECTRICAL SPECIFICATIONS
REQ71B7V3B REQ71B7W1B REQ100B7V3B REQ100B7W1B REQ125B7W1B
Power Supply Name V3 W1 V3 W1 W1
Phase 1 3N 1 3N 3N
FrequencyHz5050505050
Voltage V 230 400 230 400 400
Current Recomended fuses A 32 16 40 16 20
Voltage range Minimum V 207 360 207 360 360
Maximum V 253 440 253 440 440
Wiring
connections
For Power Supply Quantity 1 1 1 1 1
Remark 3 wires (earth wire
included)
5 wires (earth wire
included)
3 wires (earth wire
included)
5 wires (earth wire
included)
5 wires (earth wire
included)
For connection
with indoor
Quantity 11111
Remark 4 wires (earth wire included)
Power Supply Intake Outdoor unit only
NOTES
1 Sound pressure level is a relative value, depending on the distance and acoustic environment. For more details, please refer to sound level drawings of
this chapter.
2 The sound power level is an absolute value indicating the power which a sound source generates.
3 Sound values are measured in a semi-anechoic room.
4 In case of drain piping for outdoor unit, drain piping kit (option) is needed.
5 Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB, equivalent refrigerant piping : 7.5m,
level difference : 0m.
6 Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB, equivalent refrigerant piping : 7.5m,
level difference : 0m
