2 Specifications
2-1 TECHNICAL SPECIFICATIONS REQ71B7V3B REQ71B7W1B REQ100B7V3B REQ100B7W1B REQ125B7W1B
Casing Colour Daikin White
Material Painted galvanized steel plate
Dimensions Packing Height mm 900 900 1300 1300 1300
Width mm 980 980 980 980 980
Depth mm 420 420 420 420 420
Unit Height mm 770 770 1170 1170 1170
Width mm 900 900 900 900 900
Depth mm 320 320 320 320 320
Weight Machine Weight kg 83 83 102 100 108
Gross Weight kg 87 87 107 105 113
Heat Exchanger Dimensions Length mm 857 857 857 857 857
Nr of Rows22222
Fin Pitch mm 2.00 2.00 2.00 2.00 2.00
Nr of Passes 6 6 10 10 10
Face Area m² 0.641 0.641 0.980 0.980 0.980
Nr of Stages 34 34 52 52 52
Tube type Hi-XSS cooling tube
Fin Type Non-symmetric waffle louvre
Treatment Anti-corrosion treatment (PE)
Fan Type Direct Drive Propeller
Discharge direction Horizontal
Quantity 11112
Air Flow Rate
(nominal)
Cooling m³/min 48.0 48.0 55.0 55.0 89.0
Heating m³/min 43.0 43.0 50.0 50.0 80.0
MotorQuantity 11111
Model P47L11S
Position Lower
Motor Speed (nominal
at 230V)
Steps 3 3 3 3 3
Fan Motor Output W 65 65 90 90 85
Drive direct drive
Position Upper
Motor Speed (nominal
at 230V)
Steps 3
Fan Motor Output W 65
Drive direct drive
Compressor Quantity 1 1 1 1 1
Motor Model JT90G-V1N JT90G-YE JT125G-V1N JT125G-YE JT160G-YE
Type Hermetically sealed scroll compressor
Motor
Output
W 2200 2200 3000 3000 3750
Starting Method Direct
Crankcase
Heater
W3333333333
Operation Range Cooling Min
° CDB 10.0 10.0 10.0 10.0 10.0
Max
° CDB 46.0 46.0 46.0 46.0 46.0
Heating Min
° CWB -10.0 -10.0 -10.0 -10.0 -10.0
Max
° CWB 15.0 15.0 15.0 15.0 15.0
Sound Level
(nominal)
Cooling Sound
Power
dBA 65.0 65.0 70.0 70.0 70.0
Sound
Pressure
dBA 53.0 53.0 57.0 57.0 57.0
Refrigerant Type R-410A
Charge kg 2.50 2.50 3.60 3.60 3.60
Control Expansion valve (electronic type)
Nr of Circuits 11111
Refrigerant Oil Type Daphne FVC68D
Charged Volume l 1.5 1.5 1.5 1.5 1.5
