InTroduCTIon
www.DaikinApplied.com 11 IM 893-10 • ROOFPAK SINGLEZONE UNITS
Figure 12: Typical Gas Heat Panel, 1000 MBh (High TD) Figure 13: Typical Prop Exhaust Panel, 3 Fans, 460 Volt
Figure 14: VFD Bypass Panel, 40 HP, 460 Volt
S3
FSG
FSG Time
LS1
LS2
AS
IT
TD10
R22
R20
R23 R21
TB11
AFD20 GND
M51 M52 M53
