SiUS04-904 Specifications
Specifications 5
1. Specifications
1.1 SEER 16 Models
60Hz 230V
Note: The data is based on the conditions shown in the table below.
Models
Indoor Units FTXS09HVJU FTXS12HVJU
Outdoor Units
RXS09DAVJU RXS12DAVJU
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
Btu/h 8,500 (4,400~9,500) 10,000 (4,400~11,000) 11,500 (4,800~12,000) 11,500 (4,800~13,000)
Moisture Removal Pt/h 2.3 — 3.2 —
Running Current (Rated) A 4.13 4.98 5.51 4.73
Power Consumption Rated
(Min.~Max.)
W 770 (300~940) 1,070 (290~1,260) 1,290 (300~1,480) 1,000 (310~1,340)
Power Factor % 76.9 89.9 93.9 88.2
EER (Rated)
Btu/h·W
11.0 — 9.3 —
COP (Rated) W/W — 2.74 — 3.37
Energy
Efficiency
SEER/HSPF 16.0 8.8 16.0 8.8
Piping
Connections
Liquid in (mm) 1/4” (6.4 mm) 1/4” (6.4 mm)
Gas in (mm) 3/8” (9.5 mm) 3/8” (9.5 mm)
Drain in (mm) 11/16” (17.5 mm) 11/16” (17.5 mm)
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length ft (m) 65’ (20 m) 65’ (20 m)
Max. Interunit Height Difference ft (m) 49’ (15 m) 49’ (15 m)
Chargeless ft (m) 33’ (10 m) 33’ (10 m)
Amount of Additional Charge of
Refrigerant
oz/ft (kg/ft) 0.22 oz (0.006 kg) 0.22 oz (0.006 kg)
Indoor Units FTXS09HVJU FTXS12HVJU
Front Panel Color White White
Airflow Rate cfm (m³/min)
H 246 (7.0) 253 (7.2) 242 (6.8) 286 (8.1)
M 197 (5.6) 220 (6.2) 195 (5.5) 237 (6.7)
L 148 (4.2) 187 (5.3) 148 (4.2) 187 (5.3)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) in (mm) 10-3/4 × 30-7/8 × 7-11/16” (273 × 784 ×195 mm) 10-3/4× 30-7/8 × 7-11/16” (273 × 784× 195 mm)
Packaged Dimensions (H×W×D) in (mm) 10-3/16 × 32-13/16 × 12-13/16” (259×818 × 325 mm) 10-3/16 × 32-13/16 × 12-13/16” (259 × 818 × 325 mm)
Weight Lbs (kg) 16.6 lbs (7.5 kg) 16.6 lbs (7.5 kg)
Gross Weight Lbs (kg) 25.0 lbs (11.3 kg) 25.0 lbs (11.3 kg)
Operation Sound H / M / L dBA 38 / 32 / 25 38 / 33 / 28 40 / 33 / 26 39 / 34 / 29
Outdoor Units RXS09DAVJU RXS12DAVJU
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD 1YC23NXD
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge oz (kg) 12.6 oz (0.36 kg) 12.6 oz (0.36 kg)
Refrigerant
Type R-410A R-410A
Charge Lbs (kg) 1.76 Lbs (0.8 kg) 2.20 Lbs (1.0 kg)
Airflow Rate cfm (m³/min)
H 1,120 (31.7) 1,008 (28.5) 1,031 (29.2) 927 (26.3)
L 816 (23.1) 813 (23.0) 737 (20.9) 737 (20.9)
Fan
Type Propeller Propeller
Motor Output W 31 31
Running Current (Rated) A 3.93 4.8 5.33 4.6
Power Consumption (Rated) W 730 1,030 1,190 960
Power Factor % 80.4 93.3 97.1 91.7
Dimensions (H×W×D) in(mm) 21-5/8 × 30-1/8 × 11-1/4” (549 × 765 × 286 mm) 21-5/8 × 30-1/8 × 11-1/4” (549× 765 × 286 mm)
Packaged Dimensions (H×W×D) in (mm) 25 × 34-5/8 × 14-3/16” (635 × 879 × 360 mm) 25× 34-5/8× 14-3/16” (635× 879× 360 mm)
Weight Lbs (kg) 74.0 lbs (33.5 kg) 80.0 lbs (36 kg)
Gross Weight Lbs (kg) 86.0 lbs (39 kg) 92.0 lbs (41.7 kg)
Operation
Sound
H / L dBA 48 / — 49 / — 49 / — 51 / —
Drawing No. 3D062864A 3D062865A
