SiBE121021_C Outdoor Unit - 50~75 Class
Removal Procedure 389
4
Open the 2 hooks and
release the fan motor
lead wire.
îš„
When reassembling, put the
fan motor lead wire through
the back of the fan motor so
as not to be entangled with
the outdoor fan.
5
Remove the 4 screws
and remove the fan
motor.
Step
Procedure Points
Hook
(R12912)
Lead wire Outdoor fan
(R12215)
(R12913)
Fan motor
