Remote Controller SiBE121021_C
78 Printed Circuit Board Connector Wiring Diagram
2.2 Wireless Remote Controller
2.2.1 BRC7E530W/531W, BRC7F532F/533F, BRC7EA63W/66
Connectors and
Other Parts
[A3P]: Signal Receiver PCB
[A4P]: Display PCB
1) X1A Connector for display PCB
2) X2A Connector for control PCB
3) SS1 MAIN / SUB setting switch
SS2 Address setting switch
∗
Refer to page 456 for detail.
1) X1A Connector for signal receiver PCB
2) BS1 Forced operation ON/OFF button
3) LED1 (H1P) LED for operation (red)
4) LED2 (H2P) LED for timer (green)
5) LED3 (H3P) LED for filter cleaning sign (red)
6) LED4 (H4P) LED for defrost operation (orange)
