SiBE121021_C Specifications
Specifications 37
Floor Standing Type
50 Hz, 220 - 230 - 240 V
Model
FVXS25FV1B FVXS35FV1B
Cooling Heating Cooling Heating
Rated Capacity 2.5 kW Class 3.5 kW Class
Front Panel Color White White
Airflow Rates
H
m³/min
(cfm)
8.2 (290) 8.8 (311) 8.5 (300) 9.4 (332)
M 6.5 (230) 6.9 (244) 6.7 (237) 7.3 (258)
L 4.8 (169) 5.0 (177) 4.9 (173) 5.2 (184)
SL 4.1 (145) 4.4 (155) 4.5 (159) 4.7 (166)
Fan
Type Turbo Fan Turbo Fan
Motor Output W 48 48
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.14 - 0.13 - 0.12 0.15 - 0.14 - 0.13 0.14 - 0.13 - 0.12 0.15 - 0.14 - 0.13
Power Consumption (Rated) W 15 - 15 - 15 17 - 17 - 17 15 - 15 - 15 17 - 17 - 17
Power Factor (Rated) % 48.7 - 50.2 - 52.1 51.5 - 52.8 - 54.5 48.7 - 50.2 - 52.1 51.5 - 52.8 - 54.5
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 600 × 700 × 210 600 × 700 × 210
Packaged Dimensions (H × W × D) mm 696 × 786 × 286 696 × 786 × 286
Weight (Mass) kg 14 14
Gross Weight (Gross Mass) kg 18 18
Operation
Sound
H / M / L / SL dB(A) 38 / 32 / 26 / 23 38 / 32 / 26 / 23 39 / 33 / 27 / 24 39 / 33 / 27 / 24
Sound Power dB(A) 54 54 55 55
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
20.0
φ
20.0
Drawing No. 3D071661 3D071662
Model
FVXS50FV1B
Cooling Heating
Rated Capacity 5.0 kW Class
Front Panel Color White
Airflow Rates
H
m³/min
(cfm)
10.7 (378) 11.8 (417)
M 9.2 (325) 10.1 (357)
L 7.8 (275) 8.5 (300)
SL 6.6 (233) 7.1 (251)
Fan
Type Turbo Fan
Motor Output W 48
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 - 0.17 - 0.16 0.20 - 0.19 - 0.18
Power Consumption (Rated) W 27 - 27 - 27 34 - 34 - 34
Power Factor (Rated) % 68.1 - 69.1 - 70.3 77.3 - 77.8 - 78.7
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 600 × 700 × 210
Packaged Dimensions (H × W × D) mm 696 × 786 × 286
Weight (Mass) kg 14
Gross Weight (Gross Mass) kg 18
Operation
Sound
H / M / L / SL dB(A) 44 / 40 / 36 / 32 45 / 40 / 36 / 32
Sound Power dB(A) 56 57
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
12.7
Drain mm
φ
20.0
Drawing No. 3D071663
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
To Next Page
