Specifications 47
50 Hz, 230 V
Note:
The data are based on the conditions shown in the table below.
Model
4MXS80E2V3B 5MXS90E2V3B
Cooling Heating Cooling Heating
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC63BXD 2YC63BXD
Motor Output W 1,920 1,920
Refrigerant Oil
Model FVC50K FVC50K
Charge L 0.75 0.75
Refrigerant
Type R-410A R-410A
Charge kg 2.99 2.99
Airflow Rates
H
m³/min
54.5 46.0 57.1 52.5
M — 54.5 —
L 46 14.7 46.0 14.7
H
cfm
1,924 1,624 2,016 1,854
M — 1,924 —
L 1,624 519 1,624 519
Fan
Type Propeller Propeller
Motor Output W 66 66
Running Current A H: 0.97 / L: 0.69 H: 0.69 / L: 0.05 H: 1.02 / M: 0.97 / L: 0.69 H: 0.90 / L: 0.05
Power Consumption W H: 86 / L: 55 H: 55 / L: 9 H: 95 / M: 86 / L: 55 H: 78 / L: 9
Starting Current A 9.7 11.8
Dimensions (H × W × D) mm 770 × 900 × 320 770 × 900 × 320
Packaged Dimensions (H × W × D) mm 900 × 925 × 390 900 × 925 × 390
Weight (Mass) kg 72 73
Gross Weight (Gross Mass) kg 80 80
Operation Sound dB(A) 48 49 52 52
Sound Power dB(A) 60 — 66 —
Piping
Connection
Liquid mm
φ
6.4
×
4
φ
6.4
×
5
Gas mm
φ
9.5
×
1
, φ
12.7
×
1
, φ
15.9
×
2
φ
9.5
×
2
, φ
12.7
×
1,
φ
15.9
×
2
Drain mm
φ
25.0
φ
25.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring 3 for Power Supply, 4 for Interunit Wiring
Max. Interunit Piping Length
m 70 (for Total of Each Room) 75 (for Total of Each Room)
m 25 (for One Room) 25 (for One Room)
Amount of Additional Charge g/m 20 (30m or more) 20 (30m or more)
Max. Installation Height Difference
m 15 (between Indoor Unit and Outdoor Unit) 15 (between Indoor Unit and Outdoor Unit)
m 7.5 (between Indoor Units) 7.5 (between Indoor Units)
Drawing No. 3D063118 3D063119
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
7.5 m
